| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 415-56-21430 | CAB ASS'Y | 1 | SN: 11001- |
|||
| ? | 415-56-21440 | CAB ASS'Y,(WITH RADIO) | 1 | SN: 11001- |
|||
| ? | 415-56-21450 | CAB ASS'Y,(CONSTRUCTION MINISTRY) | 1 | SN: 11001- |
|||
| ? | 415-56-21460 | CAB ASS'Y,(CONSTRUCTION MINISTRY+RADIO) | 1 | SN: 11001- |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01B5 TO K0210-18B6. | ||||||
| ? | 421-926-2450 | • GLASS | 1 | SN: 11001- |
|||
| ? | 421-926-2460 | • GLASS,SIDE | 2 | SN: 11001- |
|||
| ? | 421-56-21140 | • STRIP | 1 | SN: 11001- |
|||
| ? | 421-56-21150 | • STRIP,L.H. | 1 | SN: 11001- |
|||
| ? | 421-56-21790 | • STRIP,R.H. | 1 | SN: 11001- |
|||
| ? | 419-926-2180 | • GLASS,REAR | 1 | SN: 11001- |
|||
| ? | 421-56-21170 | • STRIP | 1 | SN: 11001- |
|||
| ? | 421-56-21480 | • COVER,INSPECTION | 1 | SN: 11001- |
|||
| ? | 417-56-21560 | • SEAL | 1 | SN: 11001- |
|||
| ? | 421-56-21740 | • SEAL | 1 | SN: 11001- |
|||
| ? | 01434-00625 | • BOLT¤ WING | 2 | SN: 11001- |
|||
| ? | 01642-20608 | • WASHER | 2 | SN: 11001- |
|||
| ? | 423-56-21920 | • WASHER | 2 | SN: 11001- |
