| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (362-56-00013) | CAB ASS'Y | 1 | SN: 11272-11541 |
|||
| ? | (362-56-00012) | CAB ASS'Y | 1 | SN: 11230-11271 |
|||
| ? | (□362-56-00011) | CAB ASS'Y | 1 | SN: 10758-11229 |
|||
| ? | (□362-56-00010) | CAB ASS'Y | 1 | SN: 10001-10757 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-02A0 TO K0210-08A0. | ||||||
| ? | 362-56-41411 | • GLASS,L.H. | 1 | SN: 11272-11541 |
|||
| ? | 362-56-41410 | • GLASS,L.H. | 1 | SN: 10758-11271 |
|||
| ? | 362-56-41410 | • GLASS | 2 | SN: 10001-10757 |
|||
| ? | 363-56-31110 | • SASH ASS'Y,R.H. | 1 | SN: 10758-11541 |
|||
| ? | 363-56-31210 | • • FRAME,CENTER | 1 | SN: 10758-11541 |
|||
| ? | 425-54-16570 | • • SCREW | 2 | SN: 10758-11541 |
|||
| ? | 363-56-31120 | • • GLASS,UPPER | 1 | SN: 10758-11541 |
|||
| ? | 363-56-31230 | • • STRIP,WEATHER | 1 | SN: 10758-11541 |
|||
| ? | 363-56-31130 | • • GLASS,LOWER | 1 | SN: 10758-11541 |
|||
| ? | 363-56-31220 | • • STRIP,WEATHER | 1 | SN: 10758-11541 |
|||
| ? | 363-56-31240 | • • STRIP,WEATHER | 1 | SN: 10758-11541 |
|||
| ? | 363-56-31250 | • • RUBBER | 1 | SN: 10758-11541 |
|||
| ? | 425-54-16250 | • • LOCK ASS'Y | 1 | SN: 10758-11541 |
|||
| ? | 425-54-16270 | • • • SCREW | 1 | SN: 10758-11541 |
|||
| ? | 425-54-16280 | • • • SCREW | 2 | SN: 10758-11541 |
|||
| ? | 424-54-16260 | • • LOCK ASS'Y | 1 | SN: 10758-11541 |
|||
| ? | 425-54-16270 | • • • SCREW | 1 | SN: 10758-11541 |
|||
| ? | 425-54-16280 | • • • SCREW | 2 | SN: 10758-11541 |
|||
| ? | 421-56-11960 | • • CATCH | 2 | SN: 10758-11541 |
|||
| ? | 421-56-11970 | • • CATCH | 6 | SN: 10758-11541 |
|||
| ? | 01224-70412 | • • SCREW | 16 | SN: 10758-11541 |
|||
| ? | 01580-10403 | • • NUT | 16 | SN: 10758-11541 |
|||
| ? | 363-56-31260 | • • SEAL | 1 | SN: 10758-11541 |
|||
| ? | 363-56-31140 | • PANEL | 1 | SN: 10758-11271 |
|||
| ? | 01224-70516 | • SCREW | 7 | SN: 10758-11541 |
|||
| ? | 01580-10504 | • NUT | 7 | SN: 10758-11541 |
|||
| ? | 01642-20508 | • WASHER | 7 | SN: 10758-11541 |
|||
| ? | 362-56-42330 | • SEAL,L.H. | 1 | SN: 11272-11541 |
|||
| ? | 362-56-41420 | • SEAL | 2 | SN: 10001-11271 |
|||
| ? | 362-56-41430 | • RUBBER | 8 | SN: 10001-11271 |
|||
| ? | 362-56-41440 | • RUBBER | 8 | SN: 10001-11271 |
|||
| ? | 363-56-31150 | • WASHER,R.H. | 4 | SN: 10001-11271 |
|||
| ? | 01220-70816 | • SCREW | 8 | SN: 10001-11271 |
|||
| ? | 362-56-41990 | • WASHER | 8 | SN: 10001-11271 |
