| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 361-877-2222 | FRAME,FRONT | 1 | SN: 11380- |
|||
| ? | 361-877-2221 | FRAME,FRONT | 1 | SN: 11338-11379 |
|||
| ? | 361-877-2220 | FRAME,FRONT | 1 | SN: 10001-11337 |
|||
| ? | 361-N39-2220 | FRAME¤ FRONT,(WITH PRESSURE PICK-UP LINE) | 1 | SN: 10001- |
|||
| ? | 361-877-2160 | • SEAT (WELDED) | 1 | SN: 10001- |
|||
| ? | 361-877-2160 | • SEAT,(WITH PRESSURE PICK-UP LINE) (WELDED) | 1 | SN: 10001- |
|||
| ? | 01573-20212 | • SEAT,(WITH PRESSURE PICK-UP LINE) (WELDED) | 1 | SN: 10001- |
|||
| ? | 01010-61460 | BOLT | 4 | SN: 10001- |
|||
| ? | 01643-31445 | WASHER | 8 | SN: 10001- |
|||
| ? | 01580-01411 | NUT | 4 | SN: 10001- |
|||
| ? | 361-877-2230 | COVER | 1 | SN: 10001- |
|||
| ? | 421-09-12780 | CUSHION | 4 | SN: 10001- |
|||
| ? | 01435-00820 | BOLT | 4 | SN: 10001- |
|||
| ? | 363-46-34110 | BAR | 1 | SN: 10001- |
|||
| ? | 363-46-21360 | PIN | 2 | SN: 10001- |
|||
| ? | 361-46-23110 | PIN | 1 | SN: 10001- |
|||
| ? | 363-46-33150 | SHIM¤ 0.5MM | 14 | SN: 10001- |
|||
| ? | 361-46-23120 | SPACER | 2 | SN: 10001- |
|||
| ? | 01010-81030 | BOLT | 4 | SN: 10001- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 10001- |
|||
| ? | 363-46-33130 | PLATE | 1 | SN: 10001- |
|||
| ? | 01010-81655 | BOLT | 1 | SN: 10001- |
|||
| ? | 01643-31645 | WASHER | 1 | SN: 10001- |
|||
| ? | 01010-81030 | BOLT | 4 | SN: 10001- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 10001- |
|||
| ? | 361-46-22210 | PIN | 2 | SN: 10001- |
|||
| ? | 363-46-32140 | SHIM¤ 0.5MM | 2 | SN: 10001- |
|||
| ? | 20S-70-81760 | SPACER¤ 1.0MM | 6 | SN: 11914- |
|||
| ? | 416-46-12270 | SHIM¤ 1.0MM | 6 | SN: 10001-11913 |
|||
| ? | 01010-81220 | BOLT | 2 | SN: 10001- |
|||
| ? | 175-54-34170 | WASHER | 2 | SN: 10001- |
|||
| ? | 361-54-24112 | FENDER,L.H. | 1 | SN: 11272- |
|||
| ? | 361-54-24111 | FENDER,L.H. | 1 | SN: 10001-11271 |
|||
| ? | 361-54-24122 | FENDER,R.H. | 1 | SN: 11272- |
|||
| ? | 361-54-24121 | FENDER,R.H. | 1 | SN: 10001-11271 |
|||
| ? | 01435-00820 | BOLT | 4 | SN: 10001- |
|||
| ? | 01584-00806 | NUT | 4 | SN: 10001- |
|||
| ? | 363-93-31310 | PLATE | 1 | SN: 10001- |
