| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 361-06-22220 | WIRING HARNESS | 1 | SN: 10001-11269 |
|||
| ? | (\4\361-06-22161) | WIRING HARNESS | 1 | SN: 10130-10805 |
|||
| ? | (361-06-22220{363-06-31240)} | ||||||
| ? | 08038-00519 | • CAP | 2 | SN: 10001-@ |
|||
| ? | 415-06-12220 | • BODY,FUSE BOX | 1 | SN: 10001-@ |
|||
| ? | 415-06-12230 | • COVER | 1 | SN: 10001-@ |
|||
| ? | 283-06-16190 | • FUSE¤ 10A | 4 | SN: 10001-@ |
|||
| ? | 22W-06-13160 | • FUSE¤ 20A | 3 | SN: 10001-@ |
|||
| ? | 42A-06-12170 | • FUSE¤ 25A | 2 | SN: 10001-@ |
|||
| ? | 08020-10000 | • DIODE | 2 | SN: 10001-@ |
|||
| ? | 363-06-32210 | BRACKET | 1 | SN: 10001-11269 |
|||
| ? | 362-07-43530 | BRACKET,(FOR CAR HEATER AND DEFROSTER) | 1 | SN: 10001-11269 |
|||
| ? | 01220-40620 | SCREW | 2 | SN: 10001-@ |
|||
| ? | 01643-30623 | WASHER | 2 | SN: 10001-@ |
|||
| ? | 01435-00616 | BOLT | 6 | SN: 10001-@ |
|||
| ? | 363-06-31130 | RELAY | 10 | SN: 10001-11269 |
|||
| ? | 01435-00610 | BOLT | 10 | SN: 10001-11269 |
|||
| ? | 361-06-22151 | WIRING HARNESS | 1 | SN: 10180-11269 |
|||
| ? | 08038-00519 | • CAP | 4 | SN: 10001-11269 |
|||
| ? | 363-06-32190 | WIRING HARNESS | 1 | SN: 10001-@ |
|||
| ? | 42A-06-15140 | SWITCH,PARKING BRAKE | 1 | SN: 10001-@ |
|||
| ? | 42A-06-15120 | SWITCH,STOP LAMP | 1 | SN: 10001-@ |
|||
| ? | 417-06-11210 | SENSOR,WATER TEMPERATURE | 1 | SN: 10001-@ |
|||
| ? | 363-06-31220 | SENSOR,HST OIL TEMPERATURE | 1 | SN: 10001-@ |
|||
| ? | 361-06-22180 | WIRE | 1 | SN: 10001-@ |
|||
| ? | 01435-01016 | BOLT | 1 | SN: 10001-@ |
|||
| ? | 01435-01220 | BOLT | 1 | SN: 10001-@ |
|||
| ? | 08036-11214 | CLIP | 1 | SN: 10001-@ |
|||
| ? | 08036-01814 | CLIP | 2 | SN: 10001-@ |
|||
| ? | 08036-02514 | CLIP | 1 | SN: 10001-@ |
|||
| ? | 363-06-32230 | CLIP | 3 | SN: 10001-@ |
|||
| ? | 363-06-32240 | CLIP | 1 | SN: 10001-@ |
|||
| ? | 08053-01510 | CLIP | 2 | SN: 10001-@ |
|||
| ? | 01435-01012 | BOLT | 1 | SN: 10001-@ |
|||
| ? | 01435-01016 | BOLT | 3 | SN: 10001-@ |
|||
| ? | 08034-20519 | BAND | 16 | SN: 10770-@ |
|||
| ? | 04434-50608 | CLIP | 1 | SN: 10001-@ |
|||
| ? | 01435-00816 | BOLT | 1 | SN: 10770-@ |
|||
| ? | 01643-30823 | WASHER | 1 | SN: 10770-@ |
|||
| ? | 01435-00610 | BOLT | 2 | SN: 10001-@ |
