| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6206-71-1911) | INJECTION PUMP ASS'Y | 1 | SN: 24192- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481. | ||||||
| ? | THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | (DK105400-6550) | • GOVERNOR ASS'Y | 1 | SN: 24192- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461 AND 0462. | ||||||
| ? | DK154011-0100 | • • NUT,LOCK | 1 | SN: 24192- |
|||
| ? | DK154500-2020 | • • COVER | 1 | SN: 24192- |
|||
| ? | DK154031-3000 | • • SCREW | 1 | SN: 24192- |
|||
| ? | DK139206-0600 | • • NUT | 1 | SN: 24192- |
|||
| ? | DK154036-0300 | • • PLUG | 2 | SN: 24192- |
|||
| ? | DK020106-5040 | • • BOLT | 2 | SN: 24192- |
|||
| ? | DK154010-0300 | • • SCREW | 1 | SN: 24192- |
|||
| ? | DK020106-3840 | • • BOLT | 4 | SN: 24192- |
|||
| ? | DK154063-5100 | • • COVER | 1 | SN: 24192- |
|||
| ? | DK029020-6260 | • • BOLT | 2 | SN: 24192- |
|||
| ? | DK020006-2040 | • • BOLT | 1 | SN: 24192- |
|||
| ? | DK020006-1640 | • • BOLT | 1 | SN: 24192- |
|||
| ? | DK154150-2700 | • • SPRING,GOVERNOR | 1 | SN: 24192- |
|||
| ? | DK154158-0820 | • • CAPSULE,SPRING | 1 | SN: 24192- |
|||
| ? | DK154011-1700 | • • NUT | 1 | SN: 24192- |
|||
| ? | DK026512-1540 | • • GASKET | 2 | SN: 24192- |
|||
| ? | DK154159-1200 | • • NUT,CAP | 1 | SN: 24192- |
|||
| ? | DK154200-7120 | • • LEVER,SWIVEL | 1 | SN: 24192- |
|||
| ? | DK154204-3000 | • • BUSHING | 1 | SN: 24192- |
|||
| ? | DK029631-8020 | • • O-RING | 2 | SN: 24192- |
|||
| ? | DK016010-1640 | • • RING,SNAP | 2 | SN: 24192- |
|||
| ? | DK139611-0000 | • • SEAL,OIL | 1 | SN: 24192- |
|||
| ? | DK139411-0000 | • • SHIM ? 0.40MM | 1 | SN: 24192- |
|||
| ? | DK029311-1090 | • • SHIM ? 0.30MM | A/R | SN: 24192- |
|||
| ? | DK154204-3100 | • • BUSHING | 1 | SN: 24192- |
|||
| ? | DK025803-1310 | • • KEY ? 13MM | 1 | SN: 24192- |
|||
| ? | DK154206-2800 | • • COLLAR | 1 | SN: 24192- |
|||
| ? | DK154206-0200 | • • WASHER ? 1.0MM | A/R | SN: 24192- |
|||
| ? | DK154237-0100 | • • PIN | 1 | SN: 24192- |
|||
| ? | DK154342-5020 | • • LEVER | 1 | SN: 24192- |
|||
| ? | DK154350-7800 | • • GASKET | 1 | SN: 24192- |
|||
| ? | DK029635-2020 | • • O-RING | 1 | SN: 24192- |
|||
| ? | DK026506-1040 | • • GASKET | 2 | SN: 24192- |
|||
| ? | DK154035-1600 | • • NUT,CAP | 1 | SN: 24192- |
|||
| ? | DK154358-7200 | • • BRACKET | 1 | SN: 24192- |
