| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6206-71-1911 | INJECTION PUMP ASS'Y | 1 | SN: 24192- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481. | ||||||
| ? | THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | DK101069-9440 | • PUMP ASS'Y | 1 | SN: 24192- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 AND 0452. | ||||||
| ? | DK131073-7020 | • • HOUSING | 1 | SN: 24192- |
|||
| ? | DK029040-6020 | • • • STUD | 3 | SN: 24192- |
|||
| ? | DK131400-0100 | • • • ADAPTER | 1 | SN: 24192- |
|||
| ? | DK131420-0420 | • • • BOLT | 1 | SN: 24192- |
|||
| ? | DK131028-6020 | • • COVER | 1 | SN: 24192- |
|||
| ? | DK131011-0800 | • • • GASKET | 1 | SN: 24192- |
|||
| ? | DK131017-1000 | • • SCREW | 2 | SN: 24192- |
|||
| ? | DK029340-6020 | • • GASKET | 2 | SN: 24192- |
|||
| ? | DK139206-0400 | • • NUT | 3 | SN: 24192- |
|||
| ? | DK029633-1010 | • • O-RING | 1 | SN: 24192- |
|||
| ? | DK131371-3700 | • • CAMSHAFT | 1 | SN: 24192- |
|||
| ? | DK016630-2030 | • • BEARING | A/R | SN: 24192- |
|||
| ? | DK028201-7020 | • • BEARING | A/R | SN: 24192- |
|||
| ? | DK016640-2030 | • • BEARING | A/R | SN: 24192- |
|||
| ? | DK028202-0020 | • • BEARING | A/R | SN: 24192- |
|||
| ? | DK131302-1300 | • • RING | 1 | SN: 24192- |
|||
| ? | DK131302-1700 | • • RING | 1 | SN: 24192- |
|||
| ? | DK029312-0310 | • • SHIM ? 0.10MM | A/R | SN: 24192- |
|||
| ? | DK029312-0320 | • • SHIM ? 0.12MM | A/R | SN: 24192- |
|||
| ? | DK029312-0330 | • • SHIM ? 0.14MM | A/R | SN: 24192- |
|||
| ? | DK029312-0340 | • • SHIM ? 0.16MM | A/R | SN: 24192- |
|||
| ? | DK029312-0350 | • • SHIM ? 0.18MM | A/R | SN: 24192- |
|||
| ? | DK029312-0360 | • • SHIM ? 0.3MM | A/R | SN: 24192- |
|||
| ? | DK029312-0370 | • • SHIM ? 0.5MM | A/R | SN: 24192- |
|||
| ? | DK029312-0380 | • • SHIM ? 1.0MM | A/R | SN: 24192- |
|||
| ? | DK029311-7010 | • • SHIM ? 0.1MM | A/R | SN: 24192- |
|||
| ? | DK029311-7020 | • • SHIM ? 0.12MM | A/R | SN: 24192- |
|||
| ? | DK029311-7030 | • • SHIM ? 0.14MM | A/R | SN: 24192- |
|||
| ? | DK029311-7040 | • • SHIM ? 0.16MM | A/R | SN: 24192- |
|||
| ? | DK029311-7050 | • • SHIM ? 0.18MM | A/R | SN: 24192- |
|||
| ? | DK029311-7090 | • • SHIM ? 0.3MM | A/R | SN: 24192- |
|||
| ? | DK029311-7060 | • • SHIM ? 0.5MM | A/R | SN: 24192- |
|||
| ? | DK029311-7210 | • • SHIM ? 0.7MM | A/R | SN: 24192- |
|||
| ? | DK029311-7070 | • • SHIM ? 1.0MM | A/R | SN: 24192- |
|||
| ? | DK029311-7220 | • • SHIM ? 1.4MM | A/R | SN: 24192- |
|||
| ? | DK139417-0000 | • • SHIM ? 2.40MM | A/R | SN: 24192- |
|||
| ? | DK131306-1000 | • • BEARING,CENTER | 1 | SN: 24192- |
|||
| ? | DK029050-5010 | • • SCREW | 2 | SN: 24192- |
|||
| ? | DK026505-0940 | • • GASKET | 2 | SN: 24192- |
|||
| ? | DK029622-0190 | • • SEAL,OIL | 1 | SN: 24192- |
|||
| ? | DK131330-1800 | • • COVER | 1 | SN: 24192- |
|||
| ? | DK020006-2040 | • • BOLT | 4 | SN: 24192- |
|||
| ? | DK131321-1700 | • • GASKET | 1 | SN: 24192- |
|||
| ? | DK029470-4030 | • • KEY | 1 | SN: 24192- |
|||
| ? | DK131401-0020 | • • BOLT,EYE | 1 | SN: 24192- |
|||
| ? | DK029341-4130 | • • GASKET | 2 | SN: 24192- |
|||
| ? | DK029637-5020 | • • O-RING | 1 | SN: 24192- |
|||
| ? | DK029731-0120 | • • BOLT,EYE | 1 | SN: 24192- |
|||
| ? | DK029341-0110 | • • GASKET | 2 | SN: 24192- |
