| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 362-22-40000 | FRONT AXLE ASS'Y | 1 | SN: 26001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4430-01A0 TO F4430-03A0. | ||||||
| ? | 363-22-33210 | • HOUSING,L.H. | 1 | SN: 26001- |
|||
| ? | 07030-01030 | • BREATHER | 1 | SN: 26001- |
|||
| ? | 01010-61265 | • BOLT | 12 | SN: 26001- |
|||
| ? | 01643-31232 | • WASHER | 12 | SN: 26001- |
|||
| ? | 363-22-33150 | • PLUG | 1 | SN: 26001- |
|||
| ? | 07002-12434 | • O-RING | 1 | SN: 26001- |
|||
| ? | 363-22-32530 | • GEAR,PLANETARY | 3 | SN: 26001- |
|||
| ? | 363-22-32810 | • BEARING | 6 | SN: 26001- |
|||
| ? | 363-22-32510 | • SHAFT | 3 | SN: 26001- |
|||
| ? | 04025-00612 | • PIN,SPRING | 3 | SN: 26001- |
|||
| ? | 363-22-32610 | • CARRIER | 1 | SN: 26001- |
|||
| ? | 363-22-32251 | • HOLDER | 1 | SN: 26001- |
|||
| ? | 706-77-40310 | • BOLT | 1 | SN: 26001- |
|||
| ? | 363-22-32270 | • SHIM¤ 0.05MM | 3 | SN: 26001- |
|||
| ? | 363-22-32280 | • SHIM¤ 0.2MM | 2 | SN: 26001- |
|||
| ? | 363-22-32290 | • SHIM¤ 0.5MM | 3 | SN: 26001- |
|||
| ? | 363-22-32410 | • SHAFT | 1 | SN: 26001- |
|||
| ? | 415-22-12840 | • BEARING | 1 | SN: 26001- |
|||
| ? | 363-22-32460 | • SEAL | 1 | SN: 26001- |
|||
| ? | 415-22-11850 | • BEARING | 1 | SN: 26001- |
|||
| ? | 363-22-32540 | • GEAR,RING | 1 | SN: 26001- |
|||
| ? | 363-22-32580 | • PIN | 3 | SN: 26001- |
|||
| ? | 363-22-32421 | • SHAFT | 1 | SN: 26001- |
