| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 363-54-32310 | FRAME,FLOOR | 1 | SN: 15001- |
|||
| ? | 363-855-3280 | FRAME,FLOOR (FOR BACK HOE) | 1 | SN: 15001- |
|||
| ? | 363-855-3840 | FRAME,(FOR BACK HOE AND CAR HEATER) | 1 | SN: 15001- |
|||
| ? | 363-54-32421 | SHEET | 1 | SN: 21975- |
|||
| ? | □363-54-32420 | SHEET | 1 | SN: 15001-21974 |
|||
| ? | 363-54-32431 | SHEET | 1 | SN: 21975- |
|||
| ? | □363-54-32430 | SHEET | 1 | SN: 15001-21974 |
|||
| ? | 01435-01030 | BOLT | 4 | SN: 15001- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 15001- |
|||
| ? | 363-54-32120 | GUARD | 1 | SN: 15001- |
|||
| ? | 363-N90-3580 | GUARD,(FOR ROAD SWEEPER) | 1 | SN: 15001- |
|||
| ? | 362-N30-4260 | GUARD,(WITH INCHING LEVER) | 1 | SN: 15001- |
|||
| ? | 01435-01055 | BOLT | 2 | SN: 15001- |
|||
| ? | 01435-01035 | BOLT | 2 | SN: 15001- |
|||
| ? | 417-43-16210 | WASHER | 4 | SN: 15001- |
|||
| ? | 363-54-32130 | COVER | 1 | SN: 15001- |
|||
| ? | 363-S37-3210 | COVER,(WITH INCHING LEVER) | 1 | SN: 15001- |
|||
| ? | 363-43-37330 | FINISHER,(WITH INCHING LEVER) | 1 | SN: 15001- |
|||
| ? | 363-54-32520 | SHEET | 1 | SN: 15001-18969 |
|||
| ? | 01220-70612 | SCREW | 4 | SN: 15001- |
|||
| ? | 01642-40608 | WASHER | 4 | SN: 15001- |
|||
| ? | 363-54-32191 | BRACKET,L.H. | 1 | SN: 15001- |
|||
| ? | 363-54-32340 | BRACKET,R.H. | 1 | SN: 15001- |
|||
| ? | 01220-70616 | SCREW | 4 | SN: 15001- |
|||
| ? | 01642-40608 | WASHER | 4 | SN: 15001- |
|||
| ? | 363-54-32271 | PLATE | 1 | SN: 15001- |
|||
| ? | 01023-20614 | SCREW | 2 | SN: 22037- |
|||
| ? | 01220-70612 | SCREW | 2 | SN: 15001-22036 |
|||
| ? | 01642-40608 | WASHER | 2 | SN: 15001-22036 |
|||
| ? | 363-54-32170 | PLATE | 1 | SN: 15001- |
|||
| ? | 363-54-32470 | SHEET | 1 | SN: 18970- |
|||
| ? | 363-54-32470 | SHEET | 1 | SN: 15001-17839 |
|||
| ? | 01435-01040 | BOLT | 4 | SN: 15001- |
|||
| ? | 363-54-32280 | MAT,FLOOR | 1 | SN: 15001- |
|||
| ? | 363-Z21-3230 | MAT,FLOOR (WITH TACHOGRAPH) | 1 | SN: 15001- |
|||
| ? | 363-54-32220 | PLUG | 4 | SN: 15001- |
|||
| ? | 363-54-32320 | GRILLE | 1 | SN: 15001- |
|||
| ? | 363-855-3670 | GRILLE,(FOR BACK HOE) | 1 | SN: 15001- |
|||
| ? | 363-N39-3120 | GRILLE,(FOR PRESSURE PICK-UP LINE) | 1 | SN: 15001- |
|||
| ? | 01435-00825 | BOLT | 4 | SN: 15001- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 15001- |
|||
| ? | 363-54-34221 | SHEET,L.H. | 1 | SN: 15001- |
|||
| ? | 363-54-34221 | SHEET,R.H. | 1 | SN: 18970- |
|||
| ? | 363-54-34231 | SHEET,R.H. | 1 | SN: 15001-18969 |
|||
| ? | 363-54-34260 | PLATE | 2 | SN: 15001- |
|||
| ? | 01435-00820 | BOLT | 4 | SN: 15001- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 15001- |
|||
| ? | 363-54-34240 | COVER,L.H. | 1 | SN: 15001- |
|||
| ? | 363-54-34250 | COVER,R.H. | 1 | SN: 15001- |
|||
| ? | 01435-00820 | BOLT | 4 | SN: 15001- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 15001- |
|||
| ? | 363-54-38512 | STAY,L.H. | 1 | SN: 18970- |
|||
| ? | 363-54-35110 | BRACKET | 2 | SN: 15001-18969 |
|||
| ? | 363-54-38522 | STAY,R.H. | 1 | SN: 18970- |
|||
| ? | 01435-01030 | BOLT | 4 | SN: 18970- |
|||
| ? | 01435-00840 | BOLT | 4 | SN: 15001-18969 |
|||
| ? | 01584-00806 | NUT | 4 | SN: 15001-18969 |
|||
| ? | 01643-30823 | WASHER | 4 | SN: 15001-18969 |
|||
| ? | 363-54-26110 | MIRROR,REAR VIEW | 2 | SN: 15001- |
|||
| ? | 416-54-15170 | PLATE | 2 | SN: 19460- |
