| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 363-62-33611 | HOSE | 1 | SN: 19001- |
|||
| ? | 07000-13022 | O-RING | 1 | SN: 19001- |
|||
| ? | 363-18-31260 | ELBOW | 2 | SN: 19001- |
|||
| ? | 07000-12018 | O-RING | 2 | SN: 19001- |
|||
| ? | 363-62-33120 | ELBOW | 1 | SN: 19001- |
|||
| ? | 07000-12018 | O-RING | 1 | SN: 19001- |
|||
| ? | 416-855-2510 | NIPPLE | 1 | SN: 19001- |
|||
| ? | 363-62-33141 | HOSE | 1 | SN: 19001- |
|||
| ? | 42A-62-23120 | TUBE | 1 | SN: 19001- |
|||
| ? | 01435-01025 | BOLT | 2 | SN: 19001- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 19001- |
|||
| ? | 363-62-33150 | HOSE | 1 | SN: 19001- |
|||
| ? | 363-62-36110 | BRACKET | 1 | SN: 19001- |
|||
| ? | 01435-00816 | BOLT | 2 | SN: 19001- |
|||
| ? | 01643-30823 | WASHER | 2 | SN: 19001- |
|||
| ? | 363-62-33351 | ELBOW | 1 | SN: 19001- |
|||
| ? | 07000-12018 | O-RING | 1 | SN: 19001- |
|||
| ? | 723-11-18190 | PLUG | 1 | SN: 19001- |
|||
| ? | 07002-11023 | O-RING | 1 | SN: 19001- |
|||
| ? | 415-62-13710 | PROTECTOR | 1 | SN: 19001- |
|||
| ? | 363-62-33470 | PROTECTOR | 1 | SN: 19001- |
|||
| ? | 363-18-31410 | PROTECTOR | 1 | SN: 19001- |
