| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 600-821-6130 | ALTERNATOR A. (25A),(WITH NON HARDENING PULLEY) | 1 | SN: 15523- |
|||
| ? | KD1-09201-0530 | • BEARING,BALL¤ REAR | 1 | SN: 15523- |
|||
| ? | KD1-33926-0820 | • RETAINER | 1 | SN: 15523- |
|||
| ? | KD0-33100-1450 | • ROTOR ASS'Y | 1 | SN: 15523- |
|||
| ? | KD1-0416-04160 | • KEY,WOODRUFF | 1 | SN: 15523- |
|||
| ? | KD0-33923-0980 | • COLLAR | 1 | SN: 15523- |
|||
| ? | KD1-0055-06162 | • SCREW | 3 | SN: 15523- |
|||
| ? | KD0-35926-0060 | • RETAINER | 1 | SN: 15523- |
|||
| ? | KD1-33926-0750 | • RETAINER | 1 | SN: 15523- |
|||
| ? | KD1-0456-63057 | • BEARING,BALL¤ FRONT | 1 | SN: 15523- |
|||
| ? | KD1-33926-0730 | • RETAINER | 1 | SN: 15523- |
|||
| ? | KD1-33923-0920 | • COLLAR | 1 | SN: 15523- |
|||
| ? | KD0-33902-0080 | • NUT | 6 | SN: 15523- |
|||
| ? | KD0-33902-0090 | • NUT | 2 | SN: 15523- |
|||
| ? | KD1-33943-0980 | • BUSHING,INSULATE | 1 | SN: 15523- |
|||
| ? | KD0-33943-1050 | • BUSHING,INSULATE | 1 | SN: 15523- |
|||
| ? | KD0-33710-3300 | • REAR BRACKET A. | 1 | SN: 15523- |
|||
| ? | KD0-33784-0230 | • BAR,CONNECT | 1 | SN: 15523- |
|||
| ? | KD0-33780-0640 | • TERMINAL ASS'Y | 1 | SN: 15523- |
|||
| ? | KD0-0274-05102 | • BOLT | 1 | SN: 15523- |
|||
| ? | KD0-33719-0031 | • REGULATOR ASS'Y | 1 | SN: 15523- |
|||
| ? | KD1-33740-0450 | • • BRUSH | 2 | SN: 15523- |
|||
| ? | KD0-33730-2560 | • RECTIFIER ASS'Y | 1 | SN: 15523- |
|||
| ? | KD0-33901-0790 | • BOLT | 1 | SN: 15523- |
|||
| ? | KD0-0275-06802 | • BOLT | 3 | SN: 15523- |
|||
| ? | KD0-33200-1410 | • STATOR ASS'Y | 1 | SN: 15523- |
|||
| ? | KD0-33311-0470 | • BRACKET,FRONT | 1 | SN: 15523- |
|||
| ? | KD1-33421-0590 | • FAN | 1 | SN: 15523- |
|||
| ? | KD0-33411-2850 | • PULLEY,NON HARDENING | 1 | SN: 15523- |
|||
| ? | KD0-0280-16022 | • NUT | 1 | SN: 15523- |
|||
| ? | KD1-33951-0610 | PACKING,(NOT SHOWN) | 2 | SN: 15523- |
