| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6212-31-2170 | PISTON | 6 | SN: 25062- |
|||
| ? | □6212-31-2151 | PISTON | 6 | SN: 17739-25061 |
|||
| ? | 6211-31-2410 | PIN,PISTON | 6 | SN: 17739- |
|||
| ? | 04065-05220 | RING,SNAP | 12 | SN: 17739- |
|||
| ? | 6211-31-2050 | PISTON RING ASS'Y,PER CYLINDER | 6 | SN: 29963- |
|||
| ? | □6211-31-2033 | PISTON RING ASS'Y,PER CYLINDER | 6 | SN: 17739-29962 |
|||
| ? | (☒6211-31-2032) | PISTON RING ASS'Y,PER CYLINDER | 6 | SN: (17739-18809) |
|||
| ? | ☆ | • RING,TOP | 1 | SN: 29963- |
|||
| ? | ☆ | • RING,TOP | 1 | SN: 17739-29962 |
|||
| ? | ☆ | • RING,SECOND | 1 | SN: 18810- |
|||
| ? | ☆ | • RING,SECOND | 1 | SN: 17739-18809 |
|||
| ? | ☆ | • RING,OIL | 1 | SN: 18810- |
|||
| ? | ☆ | • RING,OIL | 1 | SN: 17739-18809 |
|||
| ? | 6211-31-3100 | CONNECTING ROD ASS'Y | 6 | SN: 17739- |
|||
| ? | ☆ | • ROD,CONNECTING | 1 | SN: 17739- |
|||
| ? | ☆ | • CAP | 1 | SN: 17739- |
|||
| ? | 6211-31-3130 | • BUSHING | 1 | SN: 17739- |
|||
| ? | 6210-31-3310 | • BOLT | 2 | SN: 17739- |
|||
| ? | 02400-10413 | • PIN,DOWEL | 2 | SN: 17739- |
|||
| ? | STANDARD | ||||||
| ? | 6210-31-3041 | METAL ASS'Y | 6 | SN: 18810- |
|||
| ? | □6210-31-3040 | METAL ASS'Y | 6 | SN: 17739-18809 |
|||
| ? | ☆ | • METAL,UPPER | 1 | SN: 18810- |
|||
| ? | ☆ | • METAL,UPPER | 1 | SN: 17739-18809 |
|||
| ? | ☆ | • METAL,LOWER | 1 | SN: 17739- |
|||
| ? | UNDERSIZE 0.25MM | ||||||
| ? | 6210-39-3041 | METAL ASS'Y | 6 | SN: 18810- |
|||
| ? | □6210-39-3040 | METAL ASS'Y | 6 | SN: 17739-18809 |
|||
| ? | ☆ | • METAL,UPPER | 1 | SN: 18810- |
|||
| ? | ☆ | • METAL,UPPER | 1 | SN: 17739-18809 |
|||
| ? | ☆ | • METAL,LOWER | 1 | SN: 17739- |
|||
| ? | UNDERSIZE 0.50MM | ||||||
| ? | 6210-38-3041 | METAL ASS'Y | 6 | SN: 18810- |
|||
| ? | □6210-38-3040 | METAL ASS'Y | 6 | SN: 17739-18809 |
|||
| ? | ☆ | • METAL,UPPER | 1 | SN: 18810- |
|||
| ? | ☆ | • METAL,UPPER | 1 | SN: 17739-18809 |
|||
| ? | ☆ | • METAL,LOWER | 1 | SN: 17739- |
|||
| ? | UNDERSIZE 0.75MM | ||||||
| ? | 6210-37-3041 | METAL ASS'Y | 6 | SN: 18810- |
|||
| ? | □6210-37-3040 | METAL ASS'Y | 6 | SN: 17739-18809 |
|||
| ? | ☆ | • METAL,UPPER | 1 | SN: 18810- |
|||
| ? | ☆ | • METAL,UPPER | 1 | SN: 17739-18809 |
|||
| ? | ☆ | • METAL,LOWER | 1 | SN: 17739- |
|||
| ? | UNDERSIZE 1.00MM | ||||||
| ? | 6210-36-3041 | METAL ASS'Y | 6 | SN: 18810- |
|||
| ? | □6210-36-3040 | METAL ASS'Y | 6 | SN: 17739-18809 |
|||
| ? | ☆ | • METAL,UPPER | 1 | SN: 18810- |
|||
| ? | ☆ | • METAL,UPPER | 1 | SN: 17739-18809 |
|||
| ? | ☆ | • METAL,LOWER | 1 | SN: 17739- |
