| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6164-21-4161 | HOUSING,FLYWHEEL | 1 | SN: 10246-@ |
|||
| ? | □6164-21-4160 | HOUSING,FLYWHEEL | 1 | SN: 10007-10245 |
|||
| ? | 07046-41410 | PLUG | 2 | SN: 10007-@ |
|||
| ? | 07046-22010 | PLUG | 1 | SN: 10007-@ |
|||
| ? | 07046-21210 | PLUG | 1 | SN: 10007-@ |
|||
| ? | 6164-21-4821 | GASKET (K2) | 1 | SN: 10007-10245 |
|||
| ? | 6164-21-4440 | BOLT | 2 | SN: 10007-@ |
|||
| ? | 01011-32055 | BOLT | 9 | SN: 10007-@ |
|||
| ? | 01010-32065 | BOLT | 2 | SN: 10007-@ |
|||
| ? | 01643-32060 | WASHER | 11 | SN: 10007-@ |
|||
| ? | 07043-01222 | PLUG | 1 | SN: 10007-@ |
|||
| ? | 07043-00415 | PLUG | 1 | SN: 10007-@ |
|||
| ? | 6136-51-4140 | PLUG | 2 | SN: 10007-@ |
|||
| ? | 07005-01612 | GASKET (K2) | 2 | SN: 10007-@ |
|||
| ? | 6164-31-7200 | GEAR ASS'Y | 1 | SN: 10007-@ |
|||
| ? | ☆ | • GEAR | 1 | SN: 10007-@ |
|||
| ? | ☆ | • WEIGHT | 1 | SN: 10007-@ |
|||
| ? | ☆ | • PIN,DOWEL | 2 | SN: 10007-@ |
|||
| ? | ☆ | • BOLT | 4 | SN: 10007-@ |
|||
| ? | 6164-31-6920 | SHAFT | 1 | SN: 10007-@ |
|||
| ? | 6164-31-6930 | BEARING | 1 | SN: 10007-@ |
|||
| ? | 6164-21-2760 | NUT | 1 | SN: 10007-@ |
|||
| ? | 6164-21-2750 | WASHER | 1 | SN: 10007-@ |
|||
| ? | 6164-21-2590 | GROMMET (K2) | 1 | SN: 10007-@ |
|||
| ? | 6164-31-6960 | BOLT | 1 | SN: 10007-@ |
|||
| ? | 01643-31645 | WASHER | 1 | SN: 10007-@ |
|||
| ? | 6164-21-2780 | BOLT | 3 | SN: 10007-@ |
|||
| ? | 6164-21-2790 | BOLT | 1 | SN: 10007-@ |
|||
| ? | 6164-21-2770 | NUT | 1 | SN: 10007-@ |
|||
| ? | 07005-01412 | GASKET (K2) | 1 | SN: 10007-@ |
|||
| ? | 6164-21-4430 | COVER | 1 | SN: 10007-@ |
|||
| ? | 07000-65160 | O-RING (K2) | 1 | SN: 10007-@ |
|||
| ? | 01010-30820 | BOLT | 5 | SN: 10007-@ |
|||
| ? | 01010-30825 | BOLT | 1 | SN: 10007-@ |
|||
| ? | 01602-00825 | WASHER,SPRING | 6 | SN: 10007-@ |
|||
| ? | 6164-21-4412 | COVER | 1 | SN: 10075-@ |
|||
| ? | □6164-21-4411 | COVER | 1 | SN: 10007-10074 |
|||
| ? | 6164-21-4421 | GASKET (K2) | 1 | SN: 10007-@ |
|||
| ? | 01010-30820 | BOLT | 9 | SN: 10007-@ |
|||
| ? | 01602-00825 | WASHER,SPRING | 9 | SN: 10007-@ |
|||
| ? | 6164-31-1300 | FLYWHEEL ASS'Y | 1 | SN: 10007-@ |
|||
| ? | ☆ | • FLYWHEEL | 1 | SN: 10007-@ |
|||
| ? | 6164-31-1340 | • GEAR,RING | 1 | SN: 10007-@ |
|||
| ? | 6164-21-4260 | SEAL¤ REAR (K2) | 1 | SN: 10007-@ |
|||
| ? | 6164-31-1571 | SHAFT | 1 | SN: 10008-@ |
|||
| ? | ▩6164-31-1570 | SHAFT | 1 | SN: 10007-10007 |
|||
| ? | (6164-31-1571{01010-31685)} | ||||||
| ? | 6164-31-1420 | GEAR | 1 | SN: 10007-@ |
|||
| ? | 04020-01228 | PIN,DOWEL | 3 | SN: 10007-@ |
|||
| ? | 01010-31685 | BOLT | 1 | SN: 10008-@ |
|||
| ? | 01010-31690 | BOLT | 1 | SN: 10007-10007 |
|||
| ? | 01643-31645 | WASHER | 1 | SN: 10007-@ |
|||
| ? | 01051-32240 | BOLT | 12 | SN: 10007-@ |
|||
| ? | 6162-13-1620 | WASHER | 12 | SN: 10007-@ |
|||
| ? | 6162-23-4501 | BARING DIVICE ASS'Y | 1 | SN: 10007-@ |
|||
| ? | ☆ | • CASE | 1 | SN: 10007-@ |
|||
| ? | ☆ | • SHAFT | 1 | SN: 10007-@ |
|||
| ? | ☆ | • SPRING | 1 | SN: 10007-@ |
|||
| ? | ☆ | • GEAR | 1 | SN: 10007-@ |
|||
| ? | ☆ | • SEAL | 1 | SN: 10007-@ |
|||
| ? | 6162-23-4531 | • PIN | 1 | SN: 10007-@ |
|||
| ? | 6150-21-4740 | GASKET (K2) | 1 | SN: 10008-@ |
|||
| ? | □07000-02055 | O-RING (K2) | 1 | SN: 10007-10007 |
|||
| ? | 01010-31030 | BOLT | 3 | SN: 10007-@ |
|||
| ? | 01602-01030 | WASHER,SPRING | 3 | SN: 10007-@ |
