| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | ▩6164-21-5210 | PAN,OIL | 1 | SN: 10040-10515 |
|||
| ? | (6164-22-5210{6164-21-5431¤} | ||||||
| ? | 6164-22-5820) | ||||||
| ? | 6164-21-5931 | GASKET (K2) | 1 | SN: 10273-@ |
|||
| ? | □6164-21-5930 | GASKET (K2) | 1 | SN: 10040-10272 |
|||
| ? | 01010-31035 | BOLT | 53 | SN: 10040-@ |
|||
| ? | (01010-31040) | BOLT | 1 | SN: 10369-@ |
|||
| ? | 01010-31035 | BOLT | 1 | SN: 10040-10368 |
|||
| ? | 01602-01030 | WASHER,SPRING | 53 | SN: 10040-@ |
|||
| ? | (01643-31032) | WASHER | 1 | SN: 10369-@ |
|||
| ? | 01602-01030 | WASHER,SPRING | 1 | SN: 10040-10368 |
|||
| ? | 02720-10607 | PLUG | 1 | SN: 10040-@ |
|||
| ? | 02720-21616 | PLUG | 3 | SN: 10040-@ |
|||
| ? | 07040-11209 | PLUG | 1 | SN: 10040-@ |
|||
| ? | 07005-01212 | GASKET (K2) | 1 | SN: 10040-@ |
|||
| ? | 07043-50108 | PLUG | 1 | SN: 10040-@ |
|||
| ? | 6127-21-5601 | VALVE ASS'Y | 1 | SN: 10040-@ |
|||
| ? | ☆ | • BODY | 1 | SN: 10040-@ |
|||
| ? | 04020-00514 | • PIN,DOWEL | 1 | SN: 10040-@ |
|||
| ? | ☆ | • VALVE | 1 | SN: 10040-@ |
|||
| ? | 6127-21-5630 | • PLUG | 1 | SN: 10040-@ |
|||
| ? | 07000-63035 | O-RING (K2) | 1 | SN: 10040-@ |
|||
| ? | 01010-31030 | BOLT | 2 | SN: 10040-@ |
|||
| ? | 01602-01030 | WASHER,SPRING | 2 | SN: 10040-@ |
|||
| ? | 01640-01016 | WASHER | 2 | SN: 10040-@ |
|||
| ? | 6162-83-8602 | LEVEL SENSOR ASS'Y | 1 | SN: 10040-@ |
|||
| ? | 6162-83-8612 | • CASE | 1 | SN: 10040-@ |
|||
| ? | 07002-23634 | • O-RING | 1 | SN: 10262-@ |
|||
| ? | 07002-23634 | • O-RING (K2) | 1 | SN: 10040-10261 |
|||
| ? | 7861-91-4550 | • SENSOR | 1 | SN: 10253-@ |
|||
| ? | (☒7861-91-4500) | • SENSOR | 1 | SN: (10253-10436) |
|||
| ? | □7861-99-4500 | • SENSOR | 1 | SN: 10040-10252 |
|||
| ? | 01010-31080 | BOLT | 2 | SN: 10040-@ |
|||
| ? | 01602-01030 | WASHER,SPRING | 2 | SN: 10040-@ |
|||
| ? | 01640-01016 | WASHER | 2 | SN: 10040-@ |
|||
| ? | 600-050-2620 | CLIP | 1 | SN: 10040-@ |
|||
| ? | 01435-21016 | BOLT | 1 | SN: 10040-@ |
|||
| ? | 6164-21-5820 | BRACKET | 1 | SN: 10040-10515 |
|||
| ? | 01010-31865 | BOLT | 2 | SN: 10040-@ |
|||
| ? | 01602-01854 | WASHER,SPRING | 2 | SN: 10040-@ |
|||
| ? | 01640-01826 | WASHER | 2 | SN: 10040-@ |
|||
| ? | 01580-01815 | NUT | 2 | SN: 10040-@ |
|||
| ? | 6164-21-5731 | HOSE | 1 | SN: 10040-@ |
|||
| ? | 07214-50813 | CONNECTOR | 1 | SN: 10040-@ |
|||
| ? | 6164-21-5751 | HOSE | 1 | SN: 10040-@ |
|||
| ? | 6164-71-5140 | JOINT | 1 | SN: 10040-@ |
|||
| ? | 07206-31014 | BOLT,JOINT | 3 | SN: 10040-@ |
|||
| ? | 07005-01412 | GASKET (K2) | 6 | SN: 10040-@ |
