| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6164-21-3111 | CASE,GEAR | 1 | SN: 10040-@ |
|||
| ? | 07043-50108 | PLUG | 2 | SN: 10040-@ |
|||
| ? | 07043-00211 | PLUG | 4 | SN: 10040-@ |
|||
| ? | 07043-00108 | PLUG | 2 | SN: 10040-10252 |
|||
| ? | 07046-13020 | PLUG | 1 | SN: 10040-@ |
|||
| ? | 6164-21-3190 | RETAINER | 1 | SN: 10040-@ |
|||
| ? | 07000-62060 | O-RING (K2) | 1 | SN: 10040-@ |
|||
| ? | 6164-21-3170 | GROMMET (K2) | 7 | SN: 10040-@ |
|||
| ? | 6164-21-3151 | GASKET (K2) | 1 | SN: 10040-10252 |
|||
| ? | 6164-21-3290 | BOLT | 4 | SN: 10040-@ |
|||
| ? | 01010-31455 | BOLT | 7 | SN: 10040-@ |
|||
| ? | 01010-31475 | BOLT | 1 | SN: 10122-@ |
|||
| ? | 01010-31485 | BOLT | 1 | SN: 10040-10121 |
|||
| ? | 01010-31490 | BOLT | 2 | SN: 10040-@ |
|||
| ? | 01602-01442 | WASHER,SPRING | 10 | SN: 10040-@ |
|||
| ? | 6164-21-3220 | COVER,GEAR CASE | 1 | SN: 10040-@ |
|||
| ? | 04020-01434 | PIN,DOWEL | 4 | SN: 10040-@ |
|||
| ? | 6164-21-3250 | GASKET (K2) | 1 | SN: 10040-@ |
|||
| ? | 07043-00211 | PLUG | 2 | SN: 10040-@ |
|||
| ? | 01010-31290 | BOLT | 12 | SN: 10040-@ |
|||
| ? | 01011-31210 | BOLT | 6 | SN: 10040-@ |
|||
| ? | 01602-01236 | WASHER,SPRING | 18 | SN: 10040-@ |
|||
| ? | 01011-31460 | BOLT | 1 | SN: 10040-@ |
|||
| ? | 01602-01442 | WASHER,SPRING | 1 | SN: 10040-@ |
|||
| ? | 6164-21-3511 | CASE | 1 | SN: 10182-@ |
|||
| ? | □6164-21-3510 | CASE | 1 | SN: 10040-10181 |
|||
| ? | 6164-21-3520 | GASKET (K2) | 1 | SN: 10182-@ |
|||
| ? | 6164-21-3520 | GASKET (K2) | 2 | SN: 10040-10181 |
|||
| ? | 6164-21-3530 | COVER | 1 | SN: 10040-10181 |
|||
| ? | 07046-11816 | PLUG | 2 | SN: 10040-@ |
|||
| ? | 01011-31210 | BOLT | 4 | SN: 10040-@ |
|||
| ? | 01011-31280 | BOLT | 8 | SN: 10040-@ |
|||
| ? | 01602-01236 | WASHER,SPRING | 12 | SN: 10040-@ |
|||
| ? | 426-01-11310 | BRACKET | 2 | SN: 10117-@ |
|||
| ? | 6164-21-6710 | BRACKET | 1 | SN: 10040-@ |
|||
| ? | 01011-31295 | BOLT | 2 | SN: 10040-@ |
|||
| ? | 01011-31215 | BOLT | 2 | SN: 10040-@ |
|||
| ? | 01602-01236 | WASHER,SPRING | 4 | SN: 10040-@ |
|||
| ? | 6165-61-3440 | BOLT | 2 | SN: 10040-@ |
|||
| ? | 01602-01442 | WASHER,SPRING | 2 | SN: 10040-@ |
|||
| ? | 6164-21-3410 | SEAL¤ FRONT (K2) | 1 | SN: 10040-@ |
|||
| ? | 6164-21-3490 | SUPPORT,FRONT | 1 | SN: 10040-@ |
|||
| ? | 6164-21-3580 | POINTER | 1 | SN: 10040-@ |
|||
| ? | 01010-31020 | BOLT | 2 | SN: 10040-@ |
|||
| ? | 01602-01030 | WASHER,SPRING | 2 | SN: 10040-@ |
