| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6138-11-5550 | MUFFLER | 1 | SN: 50195- |
|||
| ? | 6138-11-5460 | MUFFLER,(TUNNEL SPEC.) | 1 | SN: 50195- |
|||
| ? | 6206-11-5880 | • PELLET,(TUNNEL SPEC.) | 1 | SN: 50195- |
|||
| ? | 6136-11-5420 | • PELLET,(TUNNEL SPEC.) | 1 | SN: 50195- |
|||
| ? | 6138-11-5760 | MUFFLER,(SILENCED TYPE) | 1 | SN: 50195- |
|||
| ? | 6138-11-5370 | ELBOW,EXHAUST | 1 | SN: 50195- |
|||
| ? | 07042-20108 | PLUG | 1 | SN: 50195- |
|||
| ? | 01435-01045 | BOLT | 4 | SN: 54948- |
|||
| ? | □01010-31045 | BOLT | 4 | SN: 50195-54947 |
|||
| ? | 6631-11-5630 | SPACER | 4 | SN: 50195- |
|||
| ? | 6138-11-5810 | GASKET (K1) | 1 | SN: 50195- |
|||
| ? | 01435-01260 | BOLT | 4 | SN: 54948- |
|||
| ? | □01010-31260 | BOLT | 4 | SN: 50195-54947 |
|||
| ? | 6678-51-9520 | SPACER | 4 | SN: 50195- |
|||
| ? | 01584-01210 | NUT | 4 | SN: 54948- |
|||
| ? | □01580-01210 | NUT | 4 | SN: 50195-54947 |
|||
| ? | 6137-11-5770 | BRACKET,MUFFLER | 1 | SN: 50195- |
|||
| ? | 01435-01090 | BOLT | 2 | SN: 54948- |
|||
| ? | □01010-31095 | BOLT | 2 | SN: 50195-54947 |
|||
| ? | 01435-01035 | BOLT | 4 | SN: 54948- |
|||
| ? | □01010-31040 | BOLT | 4 | SN: 50195-54947 |
|||
| ? | 01602-01030 | WASHER,SPRING | 6 | SN: 50195-54947 |
|||
| ? | 01580-01008 | NUT | 4 | SN: 50195-51135 |
|||
| ? | 6138-11-5230 | JOINT | 1 | SN: 50195- |
|||
| ? | 6131-11-5360 | BOLT | 2 | SN: 50195- |
|||
| ? | 6136-12-5280 | RING,SEAL | 1 | SN: 54911- |
|||
| ? | ♦6114-11-5280 | RING,SEAL | 1 | SN: 50195-54910 |
|||
| ? | 6138-11-5750 | PIPE,DRAIN | 1 | SN: 50492- |
|||
| ? | 6137-11-5790 | PIPE,DRAIN | 1 | SN: 50195-50491 |
|||
| ? | 6711-61-5940 | CLIP | 1 | SN: 50195- |
|||
| ? | 6151-11-5590 | PIPE,EXHAUST (WITH GLASSWOOL) | 1 | SN: 50492- |
|||
| ? | ♦6691-11-5531 | PIPE,EXHAUST (WITH GLASSWOOL) | 1 | SN: 50195-50491 |
|||
| ? | 6138-11-5650 | PIPE,EXHAUST (WITHOUT GLASSWOOL) | 1 | SN: 50195- |
|||
| ? | 6138-11-5620 | CLAMP | 1 | SN: 50492- |
|||
| ? | ♦6693-12-5540 | CLAMP | 1 | SN: 50195-50491 |
|||
| ? | 6693-12-5550 | BOLT | 1 | SN: 50195- |
|||
| ? | 01582-01411 | NUT | 2 | SN: 50195- |
|||
| ? | 6151-11-5670 | WASHER | 2 | SN: 50492- |
|||
| ? | 01640-21426 | WASHER | 2 | SN: 50195-50491 |
