| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6136-21-3120 | PLATE,FRONT | 1 | SN: 50195- |
|||
| ? | 6136-21-3821 | GASKET,PLATE (K2) | 1 | SN: 50195- |
|||
| ? | 01435-00820 | BOLT | 4 | SN: 54948- |
|||
| ? | □01010-30822 | BOLT | 4 | SN: 50195-54947 |
|||
| ? | 01602-00825 | WASHER,SPRING | 4 | SN: 50195-54947 |
|||
| ? | 6136-21-3111 | COVER,FRONT | 1 | SN: 50195- |
|||
| ? | 6136-21-3812 | GASKET,FRONT COVER (K2) | 1 | SN: 50195- |
|||
| ? | 01435-00855 | BOLT | 8 | SN: 54948- |
|||
| ? | □01010-30860 | BOLT | 8 | SN: 50195-54947 |
|||
| ? | 01435-00865 | BOLT | 2 | SN: 54948- |
|||
| ? | □01010-30865 | BOLT | 2 | SN: 50195-54947 |
|||
| ? | 01435-00865 | BOLT | 4 | SN: 54948- |
|||
| ? | □01010-30870 | BOLT | 4 | SN: 50195-54947 |
|||
| ? | 01435-00875 | BOLT | 1 | SN: 54948- |
|||
| ? | □01010-30880 | BOLT | 1 | SN: 50195-54947 |
|||
| ? | 01435-00885 | BOLT | 2 | SN: 54948- |
|||
| ? | □01010-30890 | BOLT | 2 | SN: 50195-54947 |
|||
| ? | 01435-00890 | BOLT | 1 | SN: 54948- |
|||
| ? | □01010-30895 | BOLT | 1 | SN: 50195-54947 |
|||
| ? | 01602-00825 | WASHER,SPRING | 18 | SN: 50195-54947 |
|||
| ? | 01640-20816 | WASHER | 18 | SN: 50195-54947 |
|||
| ? | 6136-21-3510 | SEAL¤ FRONT (K2) | 1 | SN: 50195- |
|||
| ? | 6136-21-3631 | COVER,BEARING | 1 | SN: 50195- |
|||
| ? | 6150-71-1910 | SEAL,OIL (K2) | 1 | SN: 54947- |
|||
| ? | □6610-71-1911 | SEAL,OIL (K2) | 1 | SN: 50195-54946 |
|||
| ? | 07000-02070 | O-RING (K2) | 1 | SN: 50195- |
|||
| ? | 01435-20820 | BOLT | 4 | SN: 54948- |
|||
| ? | □01010-30825 | BOLT | 4 | SN: 50195-54947 |
|||
| ? | 01602-00825 | WASHER,SPRING | 4 | SN: 50195-54947 |
|||
| ? | 01640-20816 | WASHER | 4 | SN: 50195-54947 |
|||
| ? | 6136-81-5291 | CAP | 1 | SN: 50195- |
|||
| ? | 6130-82-5270 | GASKET | 1 | SN: 50195- |
|||
| ? | 6136-21-2410 | SHAFT,IDLER | 1 | SN: 50195- |
|||
| ? | 04025-00316 | PIN,SPRING | 1 | SN: 50195- |
|||
| ? | 6136-31-6010 | IDLER GEAR ASS'Y | 1 | SN: 50195- |
|||
| ? | ☆ | • GEAR | 1 | SN: 50195- |
|||
| ? | 6136-31-6120 | • BUSHING | 1 | SN: 50195- |
|||
| ? | 6204-31-6350 | WASHER | 1 | SN: 59888- |
|||
| ? | ▩6136-21-2420 | PLATE,THRUST | 1 | SN: 50195-59887 |
|||
| ? | (6204-31-6350{01435-01280)} | ||||||
| ? | 04025-00512 | PIN,SPRING | 1 | SN: 50195-59887 |
|||
| ? | 01435-01280 | BOLT | 1 | SN: 59888- |
|||
| ? | □01010-31280 | BOLT | 1 | SN: 59887-59887 |
|||
| ? | 01010-31275 | BOLT | 1 | SN: 50195-59886 |
