| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 600-821-8950 | ALTERNATOR A. (60A) | 1 | SN: 11027-39814 |
|||
| ? | KD0-33100-1070 | • ROTOR ASS'Y | 1 | SN: 11027-39814 |
|||
| ? | KD1-33931-0100 | • CLIP | 1 | SN: 11027-39814 |
|||
| ? | KD1-09201-0410 | • BEARING,BALL¤ REAR | 1 | SN: 11027-39814 |
|||
| ? | KD1-33926-0230 | • RETAINER | 1 | SN: 11027-39814 |
|||
| ? | KD1-33951-0420 | • PACKING | 1 | SN: 11027-39814 |
|||
| ? | KD1-33922-0070 | • PLATE | 1 | SN: 11027-39814 |
|||
| ? | KD7-33130-0230 | • RING | 1 | SN: 11027-39814 |
|||
| ? | KD1-33923-0640 | • COLLAR | 1 | SN: 11027-39814 |
|||
| ? | KD0-33926-0600 | • RETAINER | 1 | SN: 11027-39814 |
|||
| ? | KD1-33951-0380 | • RETAINER | 1 | SN: 11027-39814 |
|||
| ? | KD1-33926-0590 | • RETAINER | 1 | SN: 11027-39814 |
|||
| ? | KD1-0456-63057 | • BEARING,BALL¤ FRONT | 1 | SN: 11027-39814 |
|||
| ? | KD1-33926-0460 | • RETAINER | 1 | SN: 11027-39814 |
|||
| ? | KD1-33951-0370 | • PACKING | 1 | SN: 11027-39814 |
|||
| ? | KD1-33951-0450 | • PACKING | 1 | SN: 11027-39814 |
|||
| ? | KD1-33951-0440 | • PACKING | 1 | SN: 11027-39814 |
|||
| ? | KD1-33720-0630 | • HOLDER | 1 | SN: 11027-39814 |
|||
| ? | KD1-33943-0770 | • BUSHING,INSULATE | 1 | SN: 11027-39814 |
|||
| ? | KD1-33761-0901 | • COVER | 1 | SN: 11027-39814 |
|||
| ? | KD0-33710-2250 | • BRACKET,REAR | 1 | SN: 11027-39814 |
|||
| ? | KD1-33943-0880 | • BUSHING,INSULATE | 2 | SN: 11027-39814 |
|||
| ? | KD1-47941-0180 | • WASHER,INSULATE | 4 | SN: 11027-39814 |
|||
| ? | KD0-33730-1850 | • RECTIFIER ASS'Y | 1 | SN: 11027-39814 |
|||
| ? | KD1-33731-0500 | • • DIODE | 3 | SN: 11027-39814 |
|||
| ? | KD1-33944-0030 | • TUBE,INSULATE | 4 | SN: 11027-39814 |
|||
| ? | KD1-33784-0160 | • BAR,CONNECT | 1 | SN: 11027-39814 |
|||
| ? | KD1-33901-0251 | • BOLT | 1 | SN: 11027-39814 |
|||
| ? | KD0-33730-1860 | • RECTIFIER ASS'Y | 1 | SN: 11027-39814 |
|||
| ? | KD1-33731-0490 | • • DIODE | 3 | SN: 11027-39814 |
|||
| ? | KD1-33921-0100 | • WASHER | 2 | SN: 11027-39814 |
|||
| ? | KD1-33931-0021 | • CLIP | 2 | SN: 11027-39814 |
|||
| ? | KD1-33301-0270 | • COVER | 1 | SN: 11027-39814 |
|||
| ? | KD1-33951-0560 | • PACKING | 1 | SN: 11027-39814 |
|||
| ? | KD1-33200-0950 | • STATOR ASS'Y | 1 | SN: 11027-39814 |
|||
| ? | KD1-33310-0880 | • FRONT BRACKET ASS'Y | 1 | SN: 11027-39814 |
|||
| ? | KD0-0093-06152 | • BOLT,THROUGH | 4 | SN: 11027-39814 |
|||
| ? | KD0-33400-1990 | • PULLEY ASS'Y | 1 | SN: 11027-39814 |
