| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6151-71-1951) | INJECTION PUMP A. | 1 | SN: 19764- |
|||
| ? | DK105407-2410 | • GOVERNOR ASS'Y | 1 | SN: 19764- |
|||
| ? | DK154000-4700 | • • HOUSING,GOVERNOR | 1 | SN: 19764- |
|||
| ? | DK029632-5070 | • • O-RING | 1 | SN: 19764- |
|||
| ? | DK154007-2900 | • • PLUG | 1 | SN: 19764- |
|||
| ? | DK154350-6000 | • • PLATE | 1 | SN: 19764- |
|||
| ? | DK020106-2040 | • • BOLT | 8 | SN: 19764- |
|||
| ? | DK154010-1100 | • • SCREW | 1 | SN: 19764- |
|||
| ? | DK154011-0100 | • • NUT,LOCK | 1 | SN: 19764- |
|||
| ? | DK155404-1700 | • • CAP | 1 | SN: 19764- |
|||
| ? | DK026524-3040 | • • GASKET | 1 | SN: 19764- |
|||
| ? | DK154101-0020 | • • FLYWEIGHT ASS'Y | 1 | SN: 19764- |
|||
| ? | DK025803-1610 | • • KEY ? 16MM,WOODRUFF | 1 | SN: 19764- |
|||
| ? | DK029321-2020 | • • WASHER,SPRING | 1 | SN: 19764- |
|||
| ? | DK029231-2030 | • • NUT | 1 | SN: 19764- |
|||
| ? | DK154123-2320 | • • SLEEVE | 1 | SN: 19764- |
|||
| ? | DK029311-0010 | • • SHIM ? 0.20MM | A/R | SN: 19764- |
|||
| ? | DK029311-0180 | • • SHIM ? 0.30MM | A/R | SN: 19764- |
|||
| ? | DK029311-0190 | • • SHIM ? 0.40MM | A/R | SN: 19764- |
|||
| ? | DK139410-0000 | • • SHIM ? 0.50MM | A/R | SN: 19764- |
|||
| ? | DK029311-0210 | • • SHIM ? 1.00MM | A/R | SN: 19764- |
|||
| ? | DK139410-0100 | • • SHIM ? 1.50MM | A/R | SN: 19764- |
|||
| ? | DK154154-0500 | • • SPRING | 1 | SN: 19764- |
|||
| ? | DK154210-2720 | • • GUIDE LEVER ASS'Y | 1 | SN: 19764- |
|||
| ? | DK154230-2920 | • • LINK | 1 | SN: 19764- |
|||
| ? | DK016010-0540 | • • RING,SNAP | 1 | SN: 19764- |
|||
| ? | DK154236-4100 | • • LEVER,TENSION | 1 | SN: 19764- |
|||
| ? | DK154326-5020 | • • LEVER ASS'Y | 1 | SN: 19764- |
|||
| ? | DK154350-8700 | • • GASKET | 1 | SN: 19764- |
