Содержание Engines Komatsu S6D125-1QQ S/N 28434-UP(s6d125tc)
FUEL INJECTION PUMP (PUMP)(120050 : 0452)
Номер на схеме Каталожный номер Название Количество Детали
? 6151-71-1951 INJECTION PUMP A. 1
SN: 28434-
? DK106069-5451 • PUMP ASS'Y 1
SN: 28434-
? DK134051-2320 • • HOUSING,PUMP 1
SN: 28434-
? DK029040-6020 • • • STUD 3
SN: 28434-
? DK134311-0000 • • • RING 1
SN: 28434-
? DK134138-0000 • • • STUD 12
SN: 28434-
? DK134143-5920 • • PLUNGER ASS'Y 6
SN: 28434-
? DK134151-2220 • • • PLUNGER ASS'Y 1
SN: 28434-
? DK134110-0120 • • • VALVE,DELIVERY 1
SN: 28434-
? DK134116-4720 • • • HOLDER,DELIVERY VALVE 1
SN: 28434-
? DK029632-2070 • • • O-RING 1
SN: 28434-
? DK134117-0500 • • • STOPPER 1
SN: 28434-
? DK134112-2000 • • • SPRING 1
SN: 28434-
? DK134115-0100 • • • GASKET 1
SN: 28434-
? DK029302-0140 • • • WASHER 1
SN: 28434-
? DK134135-0200 • • • DEFLECTOR 1
SN: 28434-
? DK029602-0010 • • • RING,SNAP 1
SN: 28434-
? DK029632-9030 • • • O-RING 1
SN: 28434-
? DK029631-5020 • • • O-RING 1
SN: 28434-
? DK029631-5020 • • • O-RING 1
SN: 28434-
? DK139400-0900 • • SHIM ? 0.500MM A/R
SN: 28434-
? DK139400-1000 • • SHIM ? 0.525MM A/R
SN: 28434-
? DK139400-1100 • • SHIM ? 0.550MM A/R
SN: 28434-
? DK139400-1200 • • SHIM ? 0.575MM A/R
SN: 28434-
? DK139400-1300 • • SHIM ? 0.600MM A/R
SN: 28434-
? DK139400-1400 • • SHIM ? 0.625MM A/R
SN: 28434-
? DK139400-1500 • • SHIM ? 0.650MM A/R
SN: 28434-
? DK139400-1600 • • SHIM ? 0.675MM A/R
SN: 28434-
? DK139400-1700 • • SHIM ? 0.700MM A/R
SN: 28434-
? DK139400-1800 • • SHIM ? 0.725MM A/R
SN: 28434-
? DK139400-1900 • • SHIM ? 0.750MM A/R
SN: 28434-
? DK139400-2000 • • SHIM ? 0.775MM A/R
SN: 28434-
? DK139400-2100 • • SHIM ? 0.800MM A/R
SN: 28434-
? DK139400-2200 • • SHIM ? 0.825MM A/R
SN: 28434-
? DK139400-2300 • • SHIM ? 0.850MM A/R
SN: 28434-
? DK139400-2400 • • SHIM ? 0.875MM A/R
SN: 28434-
? DK139400-2500 • • SHIM ? 0.900MM A/R
SN: 28434-
? DK139400-2600 • • SHIM ? 0.925MM A/R
SN: 28434-
? DK139400-2700 • • SHIM ? 0.950MM A/R
SN: 28434-
? DK139400-2800 • • SHIM ? 0.975MM A/R
SN: 28434-
? DK139400-2900 • • SHIM ? 1.000MM A/R
SN: 28434-
? DK139400-3000 • • SHIM ? 1.025MM A/R
SN: 28434-
? DK139400-3100 • • SHIM ? 1.050MM A/R
SN: 28434-
? DK139400-3200 • • SHIM ? 1.075MM A/R
SN: 28434-
? DK139400-3300 • • SHIM ? 1.100MM A/R
SN: 28434-
? DK139400-3400 • • SHIM ? 1.125MM A/R
SN: 28434-
? DK139400-3500 • • SHIM ? 1.150MM A/R
SN: 28434-
? DK139400-3600 • • SHIM ? 1.175MM A/R
SN: 28434-
? DK139400-3700 • • SHIM ? 1.200MM A/R
SN: 28434-
? DK139400-3800 • • SHIM ? 1.225MM A/R
SN: 28434-
? DK139400-3900 • • SHIM ? 1.250MM A/R
SN: 28434-
? DK139400-4000 • • SHIM ? 1.275MM A/R
SN: 28434-
? DK139400-4100 • • SHIM ? 1.300MM A/R
SN: 28434-
? DK139400-4200 • • SHIM ? 1.325MM A/R
SN: 28434-
? DK139400-4300 • • SHIM ? 1.350MM A/R
SN: 28434-
? DK139400-4400 • • SHIM ? 1.375MM A/R
SN: 28434-
? DK139400-4500 • • SHIM ? 1.400MM A/R
SN: 28434-
? DK139400-4600 • • SHIM ? 1.425MM A/R
SN: 28434-
? DK139400-4700 • • SHIM ? 1.450MM A/R
SN: 28434-
? DK139400-4800 • • SHIM ? 1.475MM A/R
SN: 28434-
? DK139400-4900 • • SHIM ? 1.500MM A/R
SN: 28434-
? DK139400-5000 • • SHIM ? 1.525MM A/R
SN: 28434-
? DK139400-5100 • • SHIM ? 1.550MM A/R
SN: 28434-
? DK139400-5200 • • SHIM ? 1.575MM A/R
SN: 28434-
? DK139400-5300 • • SHIM ? 1.600MM A/R
SN: 28434-
? DK139400-5400 • • SHIM ? 1.625MM A/R
SN: 28434-
? DK139400-5500 • • SHIM ? 1.650MM A/R
SN: 28434-
? DK139400-5600 • • SHIM ? 1.675MM A/R
SN: 28434-
? DK139400-5700 • • SHIM ? 1.700MM A/R
SN: 28434-
? DK139400-5800 • • SHIM ? 1.725MM A/R
SN: 28434-
? DK139400-5900 • • SHIM ? 1.750MM A/R
SN: 28434-
? DK139400-6000 • • SHIM ? 1.775MM A/R
SN: 28434-
? DK139400-6100 • • SHIM ? 1.800MM A/R
SN: 28434-
? DK139400-6200 • • SHIM ? 1.825MM A/R
SN: 28434-
? DK139400-6300 • • SHIM ? 1.850MM A/R
SN: 28434-
? DK139400-6400 • • SHIM ? 1.875MM A/R
SN: 28434-
? DK139400-6500 • • SHIM ? 1.900MM A/R
SN: 28434-
? DK139400-6600 • • SHIM ? 1.925MM A/R
SN: 28434-
? DK139400-6700 • • SHIM ? 1.950MM A/R
SN: 28434-
? DK139400-6800 • • SHIM ? 1.975MM A/R
SN: 28434-
? DK134132-0300 • • WASHER 12
SN: 28434-
? DK013021-0040 • • NUT 12
SN: 28434-
? DK134001-0000 • • BUSHING 2
SN: 28434-
? DK134256-0000 • • RACK,CONTROL 1
SN: 28434-
? DK024030-2030 • • PIN 1
SN: 28434-
? DK134222-0000 • • BUSHING 1
SN: 28434-
? DK134241-0021 • • SLEEVE,CONTROL 6
SN: 28434-
? DK134216-0000 • • SEAT,SPRING 6
SN: 28434-
? DK134215-0400 • • SPRING,PLUNGER 6
SN: 28434-
? DK134217-0000 • • SEAT,SPRING 6
SN: 28434-
? DK134200-0020 • • TAPPET ASS'Y 6
SN: 28434-
? DK016650-2230 • • BEARING 1
SN: 28434-
? DK134303-0400 • • SHIM ? 0.60MM A/R
SN: 28434-
? DK134303-0000 • • SHIM ? 1.20MM A/R
SN: 28434-
? DK134303-0100 • • SHIM ? 1.50MM A/R
SN: 28434-
? DK134303-0200 • • SHIM ? 1.80MM A/R
SN: 28434-
? DK134303-0300 • • SHIM ? 2.00MM A/R
SN: 28434-
? DK029010-6810 • • BOLT 4
SN: 28434-
? DK134371-4000 • • CAMSHAFT 1
SN: 28434-
? DK134306-0100 • • BEARING,CENTER 1
SN: 28434-
? DK020106-2040 • • BOLT 2
SN: 28434-
? DK016650-2230 • • BEARING 1
SN: 28434-
? DK134316-1700 • • COVER 1
SN: 28434-
? DK139629-0000 • • SEAL,OIL 1
SN: 28434-
? DK134314-0000 • • SHIM ? 0.10MM A/R
SN: 28434-
? DK134314-0100 • • SHIM ? 0.12MM A/R
SN: 28434-
? DK134314-0200 • • SHIM ? 0.14MM A/R
SN: 28434-
? DK134314-0300 • • SHIM ? 0.16MM A/R
SN: 28434-
? DK134314-0400 • • SHIM ? 0.18MM A/R
SN: 28434-
? DK134314-0500 • • SHIM ? 0.30MM A/R
SN: 28434-
? DK134314-0600 • • SHIM ? 0.50MM A/R
SN: 28434-
? DK029635-5010 • • O-RING 1
SN: 28434-
? DK134563-0900 • • SLEEVE 1
SN: 28434-
? DK134043-0800 • • COVER 1
SN: 28434-
? DK134042-0100 • • GASKET 1
SN: 28434-
? DK012206-1640 • • SCREW 12
SN: 28434-
? DK134045-0100 • • PLUG 1
SN: 28434-
? DK026524-2940 • • GASKET 1
SN: 28434-
? DK014110-6440 • • WASHER,SPRING 3
SN: 28434-
? DK013020-6040 • • NUT 3
SN: 28434-
? DK131041-0500 • • GASKET 1
SN: 28434-
? DK134047-0000 • • PLUG 6
SN: 28434-
? DK025805-1910 • • KEY,WOODRUFF 1
SN: 28434-
? DK023641-8410 • • WASHER,SPRING 1
SN: 28434-
? DK134325-0700 • • NUT 1
SN: 28434-
? DK156636-8900 • • COUPLING 1
SN: 28434-
? DK134430-3520 • • BOLT,EYE 1
SN: 28434-
? DK029341-4130 • • GASKET 2
SN: 28434-
? DK029731-0120 • • BOLT,EYE 1
SN: 28434-
? DK029341-0110 • • GASKET 2
SN: 28434-
? DK029731-4680 • • BOLT,EYE 1
SN: 28434-
? DK029341-4130 • • GASKET 2
SN: 28434-
? DK131424-1520 • • VALVE,OVER FLOW 1
SN: 28434-
? DK029341-4130 • • GASKET 2
SN: 28434-
