| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 600-821-3380 | ALTERNATOR A. (13A) | 1 | SN: 26255286- |
|||
| ? | KD7-33100-0120 | • ROTOR ASS'Y | 1 | SN: 26255286- |
|||
| ? | KD1-0472-62027 | • • BEARING,BALL | 1 | SN: 26255286- |
|||
| ? | KD1-33926-0380 | • • RETAINER | 1 | SN: 26255286- |
|||
| ? | KD1-33923-0570 | • • COLLAR | 1 | SN: 26255286- |
|||
| ? | KD0-33926-0370 | • • RETAINER | 1 | SN: 26255286- |
|||
| ? | KD1-0472-63057 | • • BEARING,BALL | 1 | SN: 26255286- |
|||
| ? | KD1-44000-0581 | • REGULATOR ASS'Y | 1 | SN: 26255286- |
|||
| ? | KD1-33951-0280 | • PACKING | 1 | SN: 26255286- |
|||
| ? | KD0-33700-1961 | • REAR BRACKET ASS'Y | 1 | SN: 26255286- |
|||
| ? | KD0-33710-1341 | • • BRACKET ASS'Y | 1 | SN: 26255286- |
|||
| ? | KD1-47921-0712 | • • WASHER | 2 | SN: 26255286- |
|||
| ? | KD1-33943-0731 | • • BUSHING,INSULATE | 2 | SN: 26255286- |
|||
| ? | KD1-33951-0290 | • • PACKING | 2 | SN: 26255286- |
|||
| ? | KD1-33944-0490 | • • TUBE,B-TERMINAL | 1 | SN: 26255286- |
|||
| ? | KD1-33944-0540 | • • TUBE,R-TERMINAL | 1 | SN: 26255286- |
|||
| ? | KD1-33720-0820 | • • BRUSH HOLDER ASS'Y | 1 | SN: 26255286- |
|||
| ? | KD0-33901-0501 | • • BOLT,B-TERMINAL | 1 | SN: 26255286- |
|||
| ? | KD0-33730-1600 | • • RECTIFIER ASS'Y | 1 | SN: 26255286- |
|||
| ? | KD1-33943-0870 | • • BUSHING,INSULATE | 2 | SN: 26255286- |
|||
| ? | KD0-33901-0371 | • • BOLT,R-TERMINAL | 1 | SN: 26255286- |
|||
| ? | KD1-33785-1390 | • WIRE,READ | 1 | SN: 26255286- |
|||
| ? | KD0-0274-06652 | • BOLT,THROUGH | 4 | SN: 26255286- |
|||
| ? | KD1-33200-0981 | • STATOR ASS'Y | 1 | SN: 26255286- |
|||
| ? | KD1-33951-0270 | • PACKING | 1 | SN: 26255286- |
|||
| ? | KD1-33300-0451 | • FRONT BRACKET ASS'Y | 1 | SN: 26255286- |
|||
| ? | KD1-33761-0871 | • COVER | 1 | SN: 26255286- |
|||
| ? | KD0-33400-0701 | • PULLEY ASS'Y,NON HARDENING | 1 | SN: 26255286- |
|||
| ? | KD1-0335-18002 | • WASHER,SPRING | 1 | SN: 26255286- |
|||
| ? | KD0-0280-18022 | • NUT | 1 | SN: 26255286- |
|||
| ? | KD1-0345-05001 | • WASHER,SEAL | 3 | SN: 26255286- |
|||
| ? | KD0-0080-05322 | • BOLT | 3 | SN: 26255286- |
|||
| ? | KD7-09210-0230 | SEAL ASS'Y,(NOT SHOWN) | 1 | SN: 26255286- |
