| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 600-825-3750 | ALTERNATOR A. (35A) | 1 | SN: 26203202- |
|||
| ? | KD0-35100-0280 | • ROTOR ASS'Y | 1 | SN: 26203202- |
|||
| ? | KD1-33923-0790 | • COLLAR | 2 | SN: 26203202- |
|||
| ? | KD0-09201-0870 | • BEARING,BALL | 1 | SN: 26203202- |
|||
| ? | KD0-35300-0130 | • FRONT BRACKET ASS'Y | 1 | SN: 26203202- |
|||
| ? | KD0-35926-0070 | • • RETAINER | 1 | SN: 26203202- |
|||
| ? | KD0-35951-0060 | • • PACKING | 2 | SN: 26203202- |
|||
| ? | KD0-35926-0090 | • • RETAINER | 1 | SN: 26203202- |
|||
| ? | KD0-09201-0881 | • • BEARING,BALL | 1 | SN: 26203202- |
|||
| ? | KD1-33926-0730 | • • RETAINER | 1 | SN: 26203202- |
|||
| ? | KD0-35200-0400 | • STATOR ASS'Y | 1 | SN: 26203202- |
|||
| ? | KD0-0275-06802 | • BOLT | 3 | SN: 26203202- |
|||
| ? | KD0-35411-0210 | • PULLEY¤ HARDENING | 1 | SN: 26203202- |
|||
| ? | KD0-35421-0140 | • FAN | 1 | SN: 26203202- |
|||
| ? | KD0-35120-0450 | • FIELD COIL | 1 | SN: 26203202- |
|||
| ? | KD0-35700-0661 | • REAR BRACKET ASS'Y | 1 | SN: 26203202- |
|||
| ? | KD0-35710-0751 | • • BRACKET | 1 | SN: 26203202- |
|||
| ? | KD0-35730-0510 | • • RECTIFIER ASS'Y | 1 | SN: 26203202- |
|||
| ? | KD0-35923-0130 | • • COLLAR | 1 | SN: 26203202- |
|||
| ? | KD0-35943-0140 | • • BUSH,INSULATE | 1 | SN: 26203202- |
|||
| ? | KD0-35943-0150 | • • BUSH,INSULATE | 1 | SN: 26203202- |
|||
| ? | KD0-35943-0160 | • • BUSH,INSULATE | 1 | SN: 26203202- |
|||
| ? | KD0-35943-0170 | • • BUSH,INSULATE | 1 | SN: 26203202- |
|||
| ? | KD1-44000-0560 | • • REGULATOR ASS'Y | 1 | SN: 26203202- |
|||
| ? | KD0-09170-2501 | • • CONDENSER | 1 | SN: 26203202- |
|||
| ? | KD0-35784-0230 | • • BAR,CONNECT | 1 | SN: 26203202- |
|||
| ? | KD0-35761-0181 | • COVER,CONNECT | 1 | SN: 26203202- |
