| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6735-71-1411) | INJECTION PUMP ASS'Y | 1 | SN: 26242456- |
|||
| ? | (6735-71-1410) | INJECTION PUMP ASS'Y | 1 | SN: 26237350-26242455 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A401P-02B2 T0 A401P-06B2. | ||||||
| ? | (DK101061-9990) | • PUMP ASS'Y | 1 | SN: 26237350- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A401P-02B2 AND A401P-03B2. | ||||||
| ? | DK131034-1401 | • • PLUG | 6 | SN: 26237350- |
|||
| ? | DK131154-3920 | • • PLUNGER ASS'Y | 6 | SN: 26237350- |
|||
| ? | DK131110-8020 | • • VALVE,DELIVERY | 6 | SN: 26237350- |
|||
| ? | DK131112-5600 | • • SPRING | 6 | SN: 26237350- |
|||
| ? | DK131115-1600 | • • GASKET | 6 | SN: 26237350- |
|||
| ? | DK131116-8420 | • • HOLDER | 6 | SN: 26237350- |
|||
| ? | DK131117-3100 | • • STOPPER | 6 | SN: 26237350- |
|||
| ? | DK131122-0520 | • • PLATE ASS'Y | 3 | SN: 26237350- |
|||
| ? | DK029632-0030 | • • O-RING | 6 | SN: 26237350- |
|||
| ? | DK131200-2820 | • • TAPPET ASS'Y | 6 | SN: 26237350- |
|||
| ? | DK131203-0800 | • • • PIN | 1 | SN: 26237350- |
|||
| ? | DK131204-1000 | • • • ROLLER | 1 | SN: 26237350- |
|||
| ? | DK131205-0500 | • • • BUSHING | 1 | SN: 26237350- |
|||
| ? | DK131206-0200 | • • • GUIDE | 1 | SN: 26237350- |
|||
| ? | DK029311-0580 | • • SHIM¤ 0.2MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0590 | • • SHIM¤ 0.25MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0020 | • • SHIM¤ 0.30MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0600 | • • SHIM¤ 0.35MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0030 | • • SHIM¤ 0.40MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0610 | • • SHIM¤ 0.45MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0040 | • • SHIM¤ 0.50MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0270 | • • SHIM¤ 0.55MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0050 | • • SHIM¤ 0.6MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0280 | • • SHIM¤ 0.65MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0060 | • • SHIM¤ 0.7MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0290 | • • SHIM¤ 0.75MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0070 | • • SHIM¤ 0.8MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0310 | • • SHIM¤ 0.85MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0080 | • • SHIM¤ 0.9MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0320 | • • SHIM¤ 0.95MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0090 | • • SHIM¤ 1.0MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0330 | • • SHIM¤ 1.05MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0110 | • • SHIM¤ 1.1MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0340 | • • SHIM¤ 1.15MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0120 | • • SHIM¤ 1.2MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0350 | • • SHIM¤ 1.25MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0130 | • • SHIM¤ 1.3MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0620 | • • SHIM¤ 1.35MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0140 | • • SHIM¤ 1.4MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0630 | • • SHIM¤ 1.45MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0490 | • • SHIM¤ 1.5MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0710 | • • SHIM¤ 1.55MM | A/R | SN: 26237350- |
|||
| ? | DK029311-0500 | • • SHIM¤ 1.6MM | A/R | SN: 26237350- |
|||
| ? | DK131215-2500 | • • SPRING | 6 | SN: 26237350- |
|||
| ? | DK131216-0100 | • • SEAT,SPRING | 6 | SN: 26237350- |
|||
| ? | DK131217-0200 | • • SEAT,SPRING | 6 | SN: 26237350- |
|||
| ? | DK131256-0900 | • • RACK,CONTROL | 1 | SN: 26237350- |
|||
| ? | DK131226-0300 | • • SCREW | 1 | SN: 26237350- |
|||
| ? | DK131240-0100 | • • PINION | 6 | SN: 26237350- |
|||
| ? | DK131241-0100 | • • SLEEVE,CONTROL | 6 | SN: 26237350- |
|||
| ? | DK131242-0100 | • • SCREW | 6 | SN: 26237350- |
