| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6202-13-3300 | NOZZLE HOLDER ASS'Y | 6 | SN: 83373- |
|||
| ? | 6206-11-3100 | NOZZLE HOLDER ASS'Y | 6 | SN: 35360-83372 |
|||
| ? | 6202-13-3110 | • HOLDER ASS'Y | 1 | SN: 83373- |
|||
| ? | 6207-11-3110 | • HOLDER ASS'Y | 1 | SN: 35360-83372 |
|||
| ? | THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | DK150508-5900 | • • PIN | 2 | SN: 35360- |
|||
| ? | DK150560-0400 | • • SEAT | 1 | SN: 83373- |
|||
| ? | DK150515-9900 | • • SEAT | 1 | SN: 35360-83372 |
|||
| ? | DK150562-4300 | • • SPRING | 1 | SN: 35360- |
|||
| ? | DK150531-0000 | • • SHIM¤ 0.50MM | A/R | SN: 35360- |
|||
| ? | DK150531-0100 | • • SHIM¤ 0.525MM | A/R | SN: 35360- |
|||
| ? | DK150531-0200 | • • SHIM¤ 0.55MM | A/R | SN: 35360- |
|||
| ? | DK150531-0300 | • • SHIM¤ 0.575MM | A/R | SN: 35360- |
|||
| ? | DK150531-0400 | • • SHIM¤ 0.60MM | A/R | SN: 35360- |
|||
| ? | DK150531-0500 | • • SHIM¤ 0.625MM | A/R | SN: 35360- |
|||
| ? | DK150531-0600 | • • SHIM¤ 0.65MM | A/R | SN: 35360- |
|||
| ? | DK150531-0700 | • • SHIM¤ 0.675MM | A/R | SN: 35360- |
|||
| ? | DK150531-0800 | • • SHIM¤ 0.70MM | A/R | SN: 35360- |
|||
| ? | DK150531-0900 | • • SHIM¤ 0.725MM | A/R | SN: 35360- |
|||
| ? | DK150531-1000 | • • SHIM¤ 0.75MM | A/R | SN: 35360- |
|||
| ? | DK150531-1100 | • • SHIM¤ 0.775MM | A/R | SN: 35360- |
|||
| ? | DK150531-1200 | • • SHIM¤ 0.80MM | A/R | SN: 35360- |
|||
| ? | DK150531-1300 | • • SHIM¤ 0.825MM | A/R | SN: 35360- |
|||
| ? | DK150531-1400 | • • SHIM¤ 0.85MM | A/R | SN: 35360- |
|||
| ? | DK150531-1500 | • • SHIM¤ 0.875MM | A/R | SN: 35360- |
|||
| ? | DK150531-1600 | • • SHIM¤ 0.90MM | A/R | SN: 35360- |
|||
| ? | DK150531-1700 | • • SHIM¤ 0.925MM | A/R | SN: 35360- |
|||
| ? | DK150531-1800 | • • SHIM¤ 0.95MM | A/R | SN: 35360- |
|||
| ? | DK150531-1900 | • • SHIM¤ 0.975MM | A/R | SN: 35360- |
|||
| ? | DK150531-2000 | • • SHIM¤ 1.0MM | A/R | SN: 35360- |
|||
| ? | DK150531-2100 | • • SHIM¤ 1.025MM | A/R | SN: 35360- |
|||
| ? | DK150531-2200 | • • SHIM¤ 1.05MM | A/R | SN: 35360- |
|||
| ? | DK150531-2300 | • • SHIM¤ 1.075MM | A/R | SN: 35360- |
|||
| ? | DK150531-2400 | • • SHIM¤ 1.10MM | A/R | SN: 35360- |
|||
| ? | DK150531-2500 | • • SHIM¤ 1.125MM | A/R | SN: 35360- |
|||
| ? | DK150531-2600 | • • SHIM¤ 1.15MM | A/R | SN: 35360- |
|||
| ? | DK150531-2700 | • • SHIM¤ 1.175MM | A/R | SN: 35360- |
|||
| ? | DK150531-2800 | • • SHIM¤ 1.200MM | A/R | SN: 35360- |
|||
| ? | DK150531-2900 | • • SHIM¤ 1.225MM | A/R | SN: 35360- |
|||
| ? | DK150531-3000 | • • SHIM¤ 1.25MM | A/R | SN: 35360- |
|||
| ? | DK150531-3100 | • • SHIM¤ 1.275MM | A/R | SN: 35360- |
|||
| ? | DK150531-3200 | • • SHIM¤ 1.30MM | A/R | SN: 35360- |
|||
| ? | DK150531-3300 | • • SHIM¤ 1.325MM | A/R | SN: 35360- |
|||
| ? | DK150531-3400 | • • SHIM¤ 1.35MM | A/R | SN: 35360- |
|||
| ? | DK150531-3500 | • • SHIM¤ 1.375MM | A/R | SN: 35360- |
|||
| ? | DK150531-3600 | • • SHIM¤ 1.40MM | A/R | SN: 35360- |
|||
| ? | DK150531-3700 | • • SHIM¤ 1.425MM | A/R | SN: 35360- |
|||
| ? | DK150531-3800 | • • SHIM¤ 1.45MM | A/R | SN: 35360- |
|||
| ? | DK150531-3900 | • • SHIM¤ 1.475MM | A/R | SN: 35360- |
|||
| ? | DK150531-4000 | • • SHIM¤ 1.50MM | A/R | SN: 35360- |
|||
| ? | DK150524-4600 | • • SPACER | 1 | SN: 35360- |
|||
| ? | DK150655-0000 | • • NUT,RETAINING | 1 | SN: 35360- |
|||
| ? | 6202-13-3330 | • NOZZLE | 1 | SN: 83373- |
|||
| ? | 6206-11-3130 | • NOZZLE | 1 | SN: 35360-83372 |
|||
| ? | 6204-11-3880 | GASKET (K1) | 6 | SN: 35360- |
|||
| ? | 6204-11-3850 | SEAL,DUST (K1) | 6 | SN: 35360- |
|||
| ? | 6204-11-3810 | HOLDER | 6 | SN: 35360- |
|||
| ? | 01435-01035 | BOLT | 6 | SN: 35360- |
|||
| ? | 6204-11-3830 | WASHER | 6 | SN: 35360- |
|||
| ? | 6204-71-9100 | HOSE,SPILL | 5 | SN: 62341- |
|||
| ? | □6354-71-5310 | HOSE,SPILL | 5 | SN: 35360-62340 |
|||
| ? | 6204-71-5581 | CAP | 1 | SN: 62341- |
|||
| ? | □6204-71-5580 | CAP | 1 | SN: 35360-62340 |
|||
| ? | 6204-71-9500 | HOSE,SPILL | 1 | SN: 35360- |
|||
| ? | (☒6207-71-5310) | HOSE,SPILL | 1 | SN: (35360-83350) |
|||
| ? | 07285-00100 | CLIP | 1 | SN: 62341- |
|||
| ? | 07285-00080 | CLIP | 1 | SN: 35360-62340 |
|||
| ? | 07285-00100 | CLIP | 2 | SN: 83351- |
|||
| ? | 07285-00080 | CLIP | 2 | SN: 35360-83350 |
|||
| ? | 07285-00100 | CLIP | 10 | SN: 62341- |
|||
| ? | 08036-11214 | CLIP | 1 | SN: 83351- |
|||
| ? | 08036-10814 | CLIP | 1 | SN: 35360-83350 |
