| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (20D-22-49011) | REAR AXLE ASS'Y | 1 | SN: 3192- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.3421A TO 3429B. | ||||||
| ? | 20G-32-21601 | • BRAKE ASS'Y,(L.H.) | 1 | SN: .- |
|||
| ? | □20G-32-21600 | • BRAKE ASS'Y,(L.H.) | 1 | SN: 3192-. |
|||
| ? | 20G-32-21701 | • BRAKE ASS'Y,(R.H.) | 1 | SN: .- |
|||
| ? | □20G-32-21700 | • BRAKE ASS'Y,(R.H.) | 1 | SN: 3192-. |
|||
| ? | 20G-32-21112 | • • CALIPER ASS'Y,(L.H.) | 1 | SN: (1587)- |
|||
| ? | 20G-32-21120 | • • CALIPER ASS'Y,(R.H.) | 1 | SN: (1587)- |
|||
| ? | ☆ | • • • CALIPER,(L.H.) | 1 | SN: (1587)- |
|||
| ? | ☆ | • • • CALIPER,(R.H.) | 1 | SN: (1587)- |
|||
| ? | ☆ | • • • CALIPER,HALF | 1 | SN: 1601- |
|||
| ? | ☆ | • • • SEAL,CALIPER (K1) | 2 | SN: 1601- |
|||
| ? | ☆ | • • • BOLT,BRIDGE | 2 | SN: 3192- |
|||
| ? | ☆ | • • • BOLT,BRIDGE | 2 | SN: 3192- |
|||
| ? | ☆ | • • SEAL,PISTON (K1) | 4 | SN: 1601- |
|||
| ? | 20G-32-21230 | • • SEAL,DUST (K1) | 4 | SN: 1601- |
|||
| ? | 20G-32-21241 | • • INSERT,PISTON | 4 | SN: 1601- |
|||
| ? | 20G-32-21250 | • • RING,RETAINING | 4 | SN: 1601- |
|||
| ? | ☆ | • • PAD (K2) | 2 | SN: .- |
|||
| ? | ☆ | • • PAD (K2) | 2 | SN: 3192-. |
|||
| ? | ☆ | • • SPRING (K2) | 2 | SN: .- |
|||
| ? | 20G-32-21333 | • • PIN,SUPPORT | 2 | SN: 2301- |
|||
| ? | 20G-32-21460 | • • WASHER | 2 | SN: (1389)- |
|||
| ? | 01596-00606 | • • NUT | 2 | SN: .- |
|||
| ? | □426-09-11130 | • • NUT | 2 | SN: (1389)-. |
|||
| ? | 20G-32-21130 | • • BREATHER,BLEED | 1 | SN: (1587)- |
|||
| ? | 20G-32-21140 | • • CAP | 1 | SN: (1587)- |
|||
| ? | 20G-32-21211 | • • PISTON | 4 | SN: 1601- |
|||
| ? | 20G-32-21280 | • • BALL | 4 | SN: 1601- |
|||
| ? | 20G-32-21290 | • • O-RING | 4 | SN: (1441)- |
|||
| ? | 20G-32-21150 | • PLUG | 2 | SN: (1587)- |
|||
| ? | 20G-32-21160 | • O-RING | 1 | SN: (1587)- |
|||
| ? | 20G-32-21550 | • PLUG | 2 | SN: 3192- |
|||
| ? | 20G-32-21560 | • BLEEDER,BLEED | 1 | SN: 3192- |
|||
| ? | 20G-32-21140 | • CAP | 1 | SN: 3192- |
|||
| ? | 20G-32-21160 | • O-RING | 2 | SN: 3192- |
|||
| ? | SERVICE KIT | ||||||
| ? | (20G-32-21221) | CALIPER SEAL KIT | 2 | SN: 1601- |
|||
| ? | 20G-32-21611 | PAD KIT | 2 | SN: .- |
|||
| ? | (□20G-32-21610) | PAD KIT | 2 | SN: 2301-. |
