| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | ND445800-9054 | CORE UNIT ASS'Y | 1 | SN: 30125-30999 KIT-FLAG: _- SERIALNO: 30125-30999 |
|||
| ? | ND445800-9052 | CORE UNIT ASS'Y | 1 | SN: 30001-30124 KIT-FLAG: _- SERIALNO: 30001-30124 |
|||
| ? | ND245420-4093 | • CASE | 1 | SN: 30125-30999 KIT-FLAG: _- SERIALNO: 30125-30999 |
|||
| ? | ND245420-4092 | • CASE | 1 | SN: 30001-30124 KIT-FLAG: _- SERIALNO: 30001-30124 |
|||
| ? | ND447600-0651 | • EVAPORATOR | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND949142-0030 | • • O-RING | 2 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND077500-2580 | • THERMISTOR | 1 | SN: 30001-30999 KIT-FLAG: _- SERIALNO: 30001-30999 |
|||
| ? | ND246690-2840 | • CLAMP | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND447500-1031 | • VALVE | 1 | SN: 30125-30999 KIT-FLAG: _- SERIALNO: 30125-30999 |
|||
| ? | ND447500-1030 | • VALVE | 1 | SN: 30001-30124 KIT-FLAG: _- SERIALNO: 30001-30124 |
|||
| ? | ND446870-1990 | • TUBE | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND949142-0030 | • • O-RING | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND949142-0010 | • • O-RING | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND949046-2150 | • BOLT | 2 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND146984-5680 | • GROMMET | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND116730-0490 | • DOOR ASS'Y | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND116730-0500 | • DOOR ASS'Y | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND245420-4020 | • CASE ASS'Y | 1 | SN: 30001-30999 KIT-FLAG: _- SERIALNO: 30001-30999 |
|||
| ? | ND116452-6060 | • CASE | 1 | SN: 30001-30999 KIT-FLAG: _- SERIALNO: 30001-30999 |
|||
| ? | ND949001-1730 | • SCREW | 11 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND116420-2781 | • CORE ASS'Y | 1 | SN: 30125-30999 KIT-FLAG: _- SERIALNO: 30125-30999 |
|||
| ? | ND116420-2780 | • CORE ASS'Y | 1 | SN: 30001-30124 KIT-FLAG: _- SERIALNO: 30001-30124 |
|||
| ? | ND116427-5920 | • PIPE | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | 195-979-4841 | • HOSE, 50MM | 2 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND113600-9301 | • VALVE ASS'Y | 1 | SN: 30125-@ KIT-FLAG: _- SERIALNO: 30125-@ |
|||
| ? | ND113600-9300 | • VALVE ASS'Y | 1 | SN: 30001-30124 KIT-FLAG: _- SERIALNO: 30001-30124 |
|||
| ? | ND017265-5480 | • HOSE | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND116427-5930 | • PIPE | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND246780-4220 | • CLAMP | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND246780-4000 | • CLAMP | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND949001-2690 | • SCREW | 6 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND017732-3041 | • LEVER | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND91370-03081 | • SCREW | 3 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND017732-3060 | • LEVER | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND017732-4600 | • LEVER | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | 17M-911-3330 | • BUSHING | 2 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | 17M-911-3290 | • CLAMP | 2 | SN: 30001-30999 KIT-FLAG: _- SERIALNO: 30001-30999 |
|||
| ? | ND116662-3780 | • SHAFT | 2 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND063700-6390 | • SERVO MOTOR ASS'Y | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | 195-Z11-6280 | • BUSHING | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND90930-05201 | • SCREW | 4 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND146668-4880 | • PACKING | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND056700-8170 | • RELAY ASS'Y | 2 | SN: 30001-30999 KIT-FLAG: _- SERIALNO: 30001-30999 |
|||
| ? | 20Y-979-2680 | • RELAY | 2 | SN: 30001-30999 KIT-FLAG: _- SERIALNO: 30001-30999 |
|||
| ? | ND056700-6630 | • • RELAY | 1 | SN: 30001-30999 KIT-FLAG: _- SERIALNO: 30001-30999 |
|||
| ? | ND017660-3490 | • BRACKET | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND146525-3990 | • BRACKET | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND90930-05121 | • SCREW | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND146525-4000 | • BRACKET | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND90930-06141 | • SCREW | 2 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND949351-0720 | • CLAMP | 6 | SN: 30001-30999 KIT-FLAG: _- SERIALNO: 30001-30999 |
|||
| ? | ND246690-5150 | • CLAMP | 3 | SN: 30001-30999 KIT-FLAG: _- SERIALNO: 30001-30999 |
|||
| ? | ND443440-0030 | • SWITCH | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND949142-0160 | • • O-RING | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND949142-0040 | • • O-RING | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
|||
| ? | ND146668-2030 | • PACKING | 1 | SN: 30001-@ KIT-FLAG: _- SERIALNO: 30001-@ |
