| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6676-63-1014 | WATER PUMP ASS'Y | 1 | SN: 30180- |
|||
| ? | □6676-63-1013 | WATER PUMP ASS'Y | 1 | SN: 8019-30179 |
|||
| ? | 6685-61-1024 | • WATER PUMP ASS'Y | 1 | SN: 30180- |
|||
| ? | 6685-61-1023 | • WATER PUMP ASS'Y | 1 | SN: 8019-30179 |
|||
| ? | 6610-61-1310 | • • SHAFT | 1 | SN: 8019- |
|||
| ? | 6671-61-1111 | • • BODY,WATER PUMP | 1 | SN: 8019- |
|||
| ? | 6610-61-1511 | • • SEAL ? WATER,WATER PUMP (K4) | 1 | SN: 8019- |
|||
| ? | 6610-61-1030 | • • IMPELLER ASS'Y,WATER PUMP | 1 | SN: 8019-30179 |
|||
| ? | 6610-61-1321 | • • • IMPELLER | 1 | SN: 30180- |
|||
| ? | ☆ | • • • IMPELLER | 1 | SN: 8019-30179 |
|||
| ? | 6610-61-1331 | • • • SEAT (K4) | 1 | SN: 30180- |
|||
| ? | ☆ | • • • SEAT (K4) | 1 | SN: 8019-30179 |
|||
| ? | 6610-61-1340 | • • • FILM | 1 | SN: 8019-30179 |
|||
| ? | 02720-20204 | • • PLUG | 1 | SN: 8019- |
|||
| ? | 6600-02-3850 | • • NIPPLE | 1 | SN: 8019- |
|||
| ? | 6600-01-1221 | • • BEARING | 1 | SN: 8019- |
|||
| ? | 6610-61-1130 | • • SPACER | 1 | SN: 8019- |
|||
| ? | 6600-01-1231 | • • BEARING | 1 | SN: 8019- |
|||
| ? | 6610-61-1120 | • • RING,SNAP | 1 | SN: 8019- |
|||
| ? | 6610-69-1210 | • • FILTER,DUST (K4) | 1 | SN: 8019- |
|||
| ? | 6623-61-1350 | • PULLEY,WATER PUMP | 1 | SN: 8019- |
|||
| ? | 6610-61-1810 | GASKET (K4) | 1 | SN: 8019- |
|||
| ? | 6691-61-2803 | TENSION PULLEY A. | 1 | SN: ..- |
|||
| ? | 6691-61-2802 | TENSION PULLEY A. | 1 | SN: .-.. |
|||
| ? | 6691-61-2801 | TENSION PULLEY A. | 1 | SN: 19562-. |
|||
| ? | 6691-61-2800 | TENSION PULLEY A. | 1 | SN: 15057-19561 |
|||
| ? | 6691-61-2810 | • LEVER,TENSION PULLEY | 1 | SN: 15057-19561 |
|||
| ? | 6691-61-2811 | • LEVER,TENSION PULLEY | 1 | SN: 19562- |
|||
| ? | 6691-61-2820 | • PULLEY,TENSION | 1 | SN: 15057- |
|||
| ? | 07012-00038 | • SEAL,OIL (K4) | 1 | SN: 15057- |
|||
| ? | 06000-06205 | • BEARING | 2 | SN: 15057- |
|||
| ? | 6691-61-2850 | • SPACER | 1 | SN: 15057- |
|||
| ? | 04067-00052 | • RING,SNAP | 1 | SN: 15057- |
|||
| ? | 6691-61-2860 | • WASHER | 1 | SN: 15057- |
|||
| ? | 01050-31020 | • BOLT | 1 | SN: 15057- |
|||
| ? | 01602-01030 | • WASHER,SPRING | 1 | SN: 15057- |
|||
| ? | 6691-61-2840 | • COVER,PULLEY | 1 | SN: 15057- |
|||
| ? | 6691-61-2830 | • GASKET (K4) | 1 | SN: 15057- |
|||
| ? | 01010-30616 | • BOLT | 4 | SN: 15057- |
|||
| ? | 01602-00619 | • WASHER,SPRING | 4 | SN: 15057- |
|||
| ? | 07042-00108 | • PLUG | 1 | SN: 15057-19561 |
|||
| ? | 07043-00108 | • PLUG | 1 | SN: 19562- |
|||
| ? | 07020-00900 | • FITTING,GREASE | 1 | SN: 15057- |
|||
| ? | 07020-00000 | • FITTING,GREASE | 1 | SN: 19562- |
|||
| ? | (☒6691-61-2710) | • SHAFT | 1 | SN: (15057-.) |
|||
| ? | 6685-61-2710 | • SHAFT | 1 | SN: 15057- |
|||
| ? | 6691-61-2720 | • PLATE | 1 | SN: 15057- |
|||
| ? | 01050-31020 | • BOLT | 1 | SN: 15057- |
|||
| ? | 01602-01030 | • WASHER,SPRING | 1 | SN: 15057- |
|||
| ? | 6685-61-4372 | • BEARING | 1 | SN: 37016- |
|||
| ? | □6685-61-4371 | • BEARING | 1 | SN: 19562-37015 |
|||
| ? | 06120-03038 | • BEARING | 1 | SN: 15057-19561 |
|||
| ? | 01582-02419 | NUT | 1 | SN: 31949- |
|||
| ? | 01500-32418 | NUT | 1 | SN: 15057-31948 |
|||
| ? | 01602-02472 | WASHER,SPRING | 1 | SN: 15057- |
|||
| ? | 6685-61-4380 | SEAL,BEARING | 2 | SN: 19562- |
|||
| ? | 06122-03004 | SEAL,BEARING | 2 | SN: 15057-19561 |
|||
| ? | 6691-61-2750 | SPRING,TENSION PULLEY | 1 | SN: 15057- |
|||
| ? | 6691-61-2730 | BOLT,ADJUSTING | 1 | SN: 15057- |
|||
| ? | 01580-01411 | NUT | 1 | SN: 31949- |
|||
| ? | 01503-31411 | NUT | 1 | SN: 15057-31948 |
|||
| ? | 01580-01411 | NUT | 1 | SN: 31949- |
|||
| ? | 01504-31408 | NUT | 1 | SN: 15057-31948 |
|||
| ? | 6691-61-2740 | WASHER | 1 | SN: 15057- |
|||
| ? | 6691-61-1211 | BRACKET,WATER PUMP | 1 | SN: 15057- |
|||
| ? | (☒6691-61-1210) | BRACKET,WATER PUMP | 1 | SN: (15057-.) |
|||
| ? | 6691-61-1220 | BRACKET,(COLD WEATHER SPEC.) | 1 | SN: 19942- |
|||
| ? | 6685-61-2222 | SUPPORT,HOOK | 1 | SN: 15057- |
|||
| ? | 01050-31225 | BOLT | 2 | SN: 15057- |
|||
| ? | 01602-01236 | WASHER,SPRING | 2 | SN: 15057- |
|||
| ? | 6691-61-2110 | PULLEY | 1 | SN: 15057- |
|||
| ? | 02030-30632 | BOLT | 6 | SN: 15057- |
|||
| ? | 02300-11226 | WASHER | 6 | SN: 15057- |
|||
| ? | 6682-83-6170 | V-BELT,WATER PUMP | 1 | SN: 15057- |
|||
| ? | 6691-81-6130 | V-BELT,COOLING FAN | 2 | SN: 15057- |
