| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6115-20-1002) | CYLINDER BLOCK A. | 1 | SN: 10819- |
|||
| ? | □6115-20-1001 | CYLINDER BLOCK A. | 1 | SN: 10771-10818 |
|||
| ? | □6114-20-1002 | CYLINDER BLOCK A. | 1 | SN: 10584-10770 |
|||
| ? | 6115-21-2211 | • LINER | 4 | SN: 10819- |
|||
| ? | □6115-21-2210 | • LINER | 4 | SN: 10771-10818 |
|||
| ? | □6114-21-2211 | • LINER | 4 | SN: 10584-10770 |
|||
| ? | 6610-21-2240 | • SEAL (K2) | 4 | SN: 10584- |
|||
| ? | 6610-21-2221 | • O-RING (K2) | 4 | SN: 10584- |
|||
| ? | 6610-21-2250 | • O-RING (K2) | 4 | SN: 10584- |
|||
| ? | 6110-23-2311 | SHAFT | 3 | SN: 10584- |
|||
| ? | 6110-23-2320 | PLATE | 3 | SN: 10584- |
|||
| ? | 6110-23-2340 | PLATE | 3 | SN: 10584- |
|||
| ? | 6114-21-2330 | BOLT | 6 | SN: 10584- |
|||
| ? | 01643-31232 | WASHER | 6 | SN: 10584- |
|||
| ? | 6112-33-6300 | GEAR ASS'Y,CENTER | 1 | SN: 10584- |
|||
| ? | 6112-33-6400 | GEAR ASS'Y,L.H. | 1 | SN: 10584- |
|||
| ? | 6112-33-6500 | GEAR ASS'Y,R.H. | 1 | SN: 10584- |
|||
| ? | ☆ | • GEAR,CENTER | 1 | SN: 10584- |
|||
| ? | ☆ | • GEAR,L.H. | 1 | SN: 10584- |
|||
| ? | ☆ | • GEAR,R.H. | 1 | SN: 10584- |
|||
| ? | 6110-33-6120 | • BUSHING | 1 | SN: 10584- |
|||
| ? | 6114-21-6611 | COVER | 1 | SN: .- |
|||
| ? | □6114-21-6610 | COVER | 1 | SN: 12272-. |
|||
| ? | 6110-23-6611 | COVER | 1 | SN: 10584-12271 |
|||
| ? | 6110-21-6621 | GASKET (K2) | 1 | SN: 10584- |
|||
| ? | 01010-30814 | BOLT | 24 | SN: 10584- |
|||
| ? | 6110-21-6630 | WASHER | 23 | SN: 10584- |
|||
| ? | 6114-21-7710 | COVER | 1 | SN: 10584-12271 |
|||
| ? | 6110-21-7820 | GASKET (K2) | 1 | SN: 10584-12271 |
|||
| ? | 01602-01030 | WASHER | 4 | SN: 10584-12271 |
|||
| ? | 01582-01008 | NUT | 4 | SN: 10584-12271 |
|||
| ? | 6114-81-2110 | PLATE ? NAME,(LIMITED SUPPLY) | 1 | SN: 10584- |
|||
| ? | 04418-03060 | SCREW,(LIMITED SUPPLY) | 4 | SN: 10584- |
