| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6610-41-2010 | HOUSING ASS'Y,CAM FOLLOWER | 3 | SN: 25762- |
|||
| ? | 6610-41-2020 | • HOUSING ASS'Y,CAM FOLLOWER | 1 | SN: 25762- |
|||
| ? | 6610-41-2111 | • • HOUSING,CAM FOLLOWER | 1 | SN: .- |
|||
| ? | □6610-41-2110 | • • HOUSING,CAM FOLLOWER | 1 | SN: 25762-. |
|||
| ? | 6610-41-2130 | • • PLUG,EXPANSION | 2 | SN: 25762- |
|||
| ? | 6610-41-2140 | • SHAFT,ROCKER LEVER | 2 | SN: 25762- |
|||
| ? | 6610-41-2120 | • SCREW | 2 | SN: 25762- |
|||
| ? | 6610-41-2050 | • LEVER ASS'Y,INJECTOR | 2 | SN: 25762- |
|||
| ? | 6610-41-2060 | • • LEVER ASS'Y,INJECTOR | 1 | SN: 25762- |
|||
| ? | ☆ | • • • LEVER | 1 | SN: 25762- |
|||
| ? | 6610-41-2420 | • • • BUSHING | 1 | SN: 25762- |
|||
| ? | 6610-41-2330 | • • • SOCKET | 1 | SN: 25762- |
|||
| ? | 6610-41-3040 | • • PIN ASS'Y | 1 | SN: 25762- |
|||
| ? | ☆ | • • • PIN | 1 | SN: 25762- |
|||
| ? | 6610-41-2360 | • • • PLUG | 1 | SN: 25762- |
|||
| ? | 6610-41-2370 | • • • PIN,SPRING | 1 | SN: 25762- |
|||
| ? | 6610-41-2440 | • • ROLLER | 1 | SN: 25762- |
|||
| ? | 6610-41-2030 | • LEVER ASS'Y,INTAKE AND EXHAUST | 4 | SN: 25762- |
|||
| ? | 6610-41-2040 | • • LEVER ASS'Y,INTAKE AND EXHAUST | 1 | SN: 25762- |
|||
| ? | ☆ | • • • LEVER | 1 | SN: 25762- |
|||
| ? | ☆ | • • • BUSHING | 1 | SN: 25762- |
|||
| ? | 6610-41-2330 | • • • SOCKET | 1 | SN: 25762- |
|||
| ? | 6610-41-3050 | • • PIN ASS'Y | 1 | SN: 25762- |
|||
| ? | ☆ | • • • PIN | 1 | SN: 25762- |
|||
| ? | 6610-41-2360 | • • • PLUG | 1 | SN: 25762- |
|||
| ? | 6610-41-2370 | • • PIN,SPRING | 1 | SN: 25762- |
|||
| ? | 6610-41-2340 | • • ROLLER | 1 | SN: 25762- |
|||
| ? | 6710-41-3020 | ROD ASS'Y,EXHAUST | 6 | SN: 107183- |
|||
| ? | □6610-41-3020 | ROD ASS'Y,EXHAUST | 6 | SN: 25762-107182 |
|||
| ? | ☆ | • ROD,EXHAUST | 1 | SN: 107183- |
|||
| ? | ☆ | • ROD,EXHAUST | 1 | SN: 25762-107182 |
|||
| ? | 6610-41-3030 | ROD ASS'Y,INJECTOR | 6 | SN: 25762- |
|||
| ? | ☆ | • ROD,INJECTOR | 1 | SN: 25762- |
|||
| ? | 6710-41-3010 | ROD ASS'Y,INTAKE | 6 | SN: 107183- |
|||
| ? | □6610-41-3010 | ROD ASS'Y,INTAKE | 6 | SN: 25762-107182 |
|||
| ? | ☆ | • ROD,INTAKE | 1 | SN: 107183- |
|||
| ? | ☆ | • ROD,INTAKE | 1 | SN: 25762-107182 |
|||
| ? | 6610-41-2081 | GASKET ASS'Y (K2) | 1 | SN: 159720- |
|||
| ? | 6610-41-2080 | GASKET ASS'Y (K2) | 1 | SN: 25762-159719 |
|||
| ? | 6610-41-2810 | • GASKET ? 0.80MM | 3 | SN: 25762- |
|||
| ? | 6610-41-2820 | • GASKET ? 0.38MM | 3 | SN: 159720- |
|||
| ? | 6610-41-2820 | • GASKET ? 0.38MM | 6 | SN: 25762-159719 |
|||
| ? | 6610-41-2840 | • GASKET ? 0.38MM | 3 | SN: 159720- |
|||
| ? | 6610-41-2830 | • GASKET ? 0.18MM | 9 | SN: 25762- |
|||
| ? | 02030-20625 | BOLT | 18 | SN: 25762- |
|||
| ? | 02310-11224 | WASHER,SPRING | 18 | SN: 25762- |
|||
| ? | 02300-11320 | WASHER | 18 | SN: 25762- |
