| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6658-31-1041 | FLYWHEEL ASS'Y | 1 | SN: 25762- |
|||
| ? | ☆ | • FLYWHEEL | 1 | SN: 25762- |
|||
| ? | 6673-31-1321 | • GEAR | 1 | SN: 25762- |
|||
| ? | 6658-31-1370 | GEAR,RING | 1 | SN: 25762- |
|||
| ? | 6670-31-1330 | PIN,DRIVE | 2 | SN: 25762- |
|||
| ? | 6631-31-1341 | BOLT | 6 | SN: 118436- |
|||
| ? | 6631-31-1340 | BOLT | 6 | SN: 25762-118435 |
|||
| ? | 6610-31-3331 | WASHER | 6 | SN: 118436- |
|||
| ? | 6610-31-1362 | PLATE,LOCK (K2) | 3 | SN: 25762-118435 |
|||
| ? | 6658-21-4021 | HOUSING ASS'Y,FLYWHEEL | 1 | SN: 25768- |
|||
| ? | 6658-21-4020 | HOUSING ASS'Y,FLYWHEEL | 1 | SN: 25762-25767 |
|||
| ? | 6657-22-4111 | • HOUSING,FLYWHEEL | 1 | SN: 25768- |
|||
| ? | 6657-22-4110 | • HOUSING,FLYWHEEL | 1 | SN: 25762-25767 |
|||
| ? | 07046-12016 | • PLUG,EXPANSION | 2 | SN: 25762- |
|||
| ? | 07043-00108 | • PLUG | 1 | SN: 25762- |
|||
| ? | 02030-20570 | BOLT | 4 | SN: 25762- |
|||
| ? | 6600-01-2112 | BOLT | 3 | SN: .- |
|||
| ? | □6600-01-2111 | BOLT | 3 | SN: 25762-. |
|||
| ? | 6631-21-4591 | BOLT | 1 | SN: .- |
|||
| ? | □6631-21-4590 | BOLT | 1 | SN: 25762-. |
|||
| ? | 6600-01-2740 | WASHER,SPRING | 8 | SN: 25762- |
|||
| ? | 04530-02438 | BOLT,EYE | 2 | SN: 25762- |
|||
| ? | 07044-02412 | PLUG | 1 | SN: 25762- |
|||
| ? | 07000-03022 | O-RING (K2) | 1 | SN: 25762- |
|||
| ? | 6610-21-4581 | GASKET (K2) | 1 | SN: .- |
|||
| ? | □6610-21-4580 | GASKET (K2) | 1 | SN: 25762-. |
|||
| ? | 600-512-1220 | PLUG | 1 | SN: 25762-25767 |
|||
| ? | 07005-01012 | GASKET | 1 | SN: 25762-25767 |
|||
| ? | 6658-51-9430 | PIPE | 1 | SN: 25768- |
|||
| ? | 07000-02060 | O-RING (K2) | 1 | SN: 25768- |
|||
| ? | 6657-52-9442 | CONNECTOR,(FOR FRONT ENGINE) | 1 | SN: 33930-34674 |
|||
| ? | 6657-52-9442 | CONNECTOR,(FOR REAR ENGINE) | 1 | SN: .-35759 |
|||
| ? | □6657-52-9441 | CONNECTOR | 1 | SN: 33930-. |
|||
| ? | 6657-52-9440 | CONNECTOR | 1 | SN: 32139-33929 |
|||
| ? | 6658-51-9440 | CONNECTOR | 1 | SN: 25768-32138 |
|||
| ? | 07000-03040 | O-RING (K2) | 1 | SN: 25768- |
|||
| ? | 01040-31465 | BOLT | 4 | SN: 25768- |
|||
| ? | 01602-01442 | WASHER,SPRING | 4 | SN: 25768- |
