| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 21S-98-21110 | CHART ? OIL | 1 | SN: 15001- |
|||
| ? | 21S-946-2911 | PLATE ? DATA | 1 | SN: 15001- |
|||
| ? | 20A-98-11180 | PLATE ? OPERATING,ENGINE CONTROL | 1 | SN: 15001- |
|||
| ? | 09685-00002 | PLATE ? OPERATING,WORK EQUIPMENT LOCK LEVER | 1 | SN: 15001- |
|||
| ? | 21S-98-21130 | PLATE ? OPERATING,WORK EQUIPMENT | 1 | SN: 15001- |
|||
| ? | 21R-98-12220 | PLATE ? OPERATING,SWING PEDAL | 1 | SN: 15001- |
|||
| ? | 20A-98-11140 | PLATE ? OPERATING,STARTING SWITCH | 1 | SN: 15001- |
|||
| ? | 09685-00002 | PLATE ? OPERATING,SWING LOCK LEVER | 1 | SN: 15001- |
|||
| ? | 20A-98-11150 | PLATE ? CAUTION,ENGINE OIL | 1 | SN: 15001- |
|||
| ? | 21R-98-12130 | PLATE ? MARK,TURNING AREA | 1 | SN: 15001- |
|||
| ? | 21R-98-12160 | PLATE ? MARK,KEEP OUT | 1 | SN: 15001- |
|||
| ? | 21A-98-11210 | PLATE ? CAUTION,STARTING AND LEAVING SEAT | 1 | SN: 15001- |
|||
| ? | 20A-98-11310 | PLATE ? CAUTION,FUEL TANK | 1 | SN: 15001- |
|||
| ? | 21S-98-21140 | PLATE ? INSTRUCTION,LUBRICATION | 1 | SN: 15001- |
|||
| ? | 09668-00100 | PLATE ? SAFETY,RADIATOR CAP | 1 | SN: 15001- |
|||
| ? | 21S-98-11120 | PLATE ? CAUTION,HYDRAULIC OIL | 1 | SN: 15001- |
|||
| ? | 20A-98-11330 | PLATE ? INSTRUCTION,FUSE BOX | 1 | SN: 15001- |
|||
| ? | 20A-98-11340 | PLATE ? INSTRUCTION,ARROW | 2 | SN: 15001- |
|||
| ? | 09690-C0200 | PLATE ? MARK,KOMATSU | 1 | SN: 15001- |
|||
| ? | 09690-C0160 | PLATE ? MARK,KOMATSU | 1 | SN: 15001- |
|||
| ? | 21S-98-21210 | PLATE ? MARK,PC03 | 2 | SN: 15001- |
|||
| ? | 21A-98-11410 | PLATE ? MARK,MICRO SHOVEL | 2 | SN: 15001- |
|||
| ? | 21R-98-12420 | PLATE,NONSKID | 3 | SN: 15001- |
|||
| ? | 21A-98-18120 | PLATE ? NAME,(LIMITED SUPPLY) | 1 | SN: 15001- |
|||
| ? | 04418-13060 | SCREW | 4 | SN: 15001- |
|||
| ? | 21S-946-2920 | PLATE | 1 | SN: 15001- |
|||
| ? | 21S-946-2930 | PLATE | 1 | SN: 15001- |
|||
| ? | 20A-98-11350 | PLATE ? MARK,GAS (NOT SHOWN) | 1 | SN: 15001- |
