| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6631-11-4110 | MANIFOLD,AIR INTAKE | 1 | SN: 116563- |
|||
| ? | 02720-20204 | PLUG | 1 | SN: 116563- |
|||
| ? | 6610-11-4812 | GASKET (K1) | 3 | SN: 116563- |
|||
| ? | (☒6610-11-4811) | GASKET (K1) | 3 | SN: (116563-.) |
|||
| ? | 02010-20657 | BOLT | 9 | SN: 116563- |
|||
| ? | 02310-11224 | WASHER,SPRING | 9 | SN: 116563- |
|||
| ? | 02300-11320 | WASHER | 9 | SN: 116563- |
|||
| ? | 6691-11-4440 | CONNECTOR,AIR | 1 | SN: 116563- |
|||
| ? | 6685-11-4222 | GASKET (K1) | 1 | SN: 116563- |
|||
| ? | 6691-11-4480 | CONNECTOR | 1 | SN: 116563- |
|||
| ? | 02895-67075 | O-RING (K1) | 2 | SN: 116563- |
|||
| ? | 6657-12-4720 | HOSE | 1 | SN: 116563- |
|||
| ? | 600-714-1250 | CLAMP | 2 | SN: 116563- |
|||
| ? | 01010-31235 | BOLT | 3 | SN: 116563- |
|||
| ? | 01010-31245 | BOLT | 2 | SN: 116563- |
|||
| ? | 01602-01236 | WASHER,SPRING | 5 | SN: 116563- |
|||
| ? | 01640-01226 | WASHER | 5 | SN: 116563- |
|||
| ? | 6675-11-4950 | COVER | 1 | SN: 116563- |
|||
| ? | 6610-21-2720 | PLUG | 1 | SN: 116563- |
|||
| ? | 600-815-2110 | GLOW PLUG | 1 | SN: 118436- |
|||
| ? | 6610-81-4211 | GLOW PLUG ASS'Y | 1 | SN: 116563-118435 |
|||
| ? | 600-815-2190 | • GASKET | 1 | SN: 118436- |
|||
| ? | 6610-81-4230 | • GASKET | 1 | SN: 116563-118435 |
|||
| ? | 6610-81-4103 | NOZZLE ASS'Y,PREHEATER | 1 | SN: 116563- |
|||
| ? | 6610-81-4112 | • NOZZLE ASS'Y,PREHEATER | 1 | SN: 116563- |
|||
| ? | 6610-81-4120 | • PLATE | 1 | SN: 116563- |
|||
| ? | 6610-81-4132 | • ADAPTER | 1 | SN: 116563- |
|||
| ? | 6610-81-4140 | • PIN,SPRING | 1 | SN: 116563- |
|||
| ? | 6610-81-4240 | • O-RING | 1 | SN: 116563- |
|||
| ? | 6610-81-4150 | • GASKET | 1 | SN: 116563- |
|||
| ? | 6610-81-8820 | ELBOW | 1 | SN: 116563- |
|||
| ? | 6675-11-4960 | GASKET (K1) | 1 | SN: 116563- |
|||
| ? | 01010-30825 | BOLT | 4 | SN: 116563- |
|||
| ? | 01602-00825 | WASHER,SPRING | 4 | SN: 116563- |
|||
| ? | 01640-00816 | WASHER | 4 | SN: 116563- |
|||
| ? | 01580-01008 | NUT | 8 | SN: 116563- |
|||
| ? | 01602-01030 | WASHER,SPRING | 8 | SN: 116563- |
|||
| ? | 01642-01016 | WASHER | 8 | SN: 116563- |
|||
| ? | 6691-11-4540 | BRACKET,AIR CLEANER | 1 | SN: 116563- |
|||
| ? | 01010-31025 | BOLT | 4 | SN: 116563- |
|||
| ? | 01602-01030 | WASHER,SPRING | 4 | SN: 116563- |
|||
| ? | 6691-11-4960 | CONNECTOR,AIR | 1 | SN: 116563- |
|||
| ? | 6691-11-4970 | CONNECTOR,AIR | 1 | SN: 116563- |
|||
| ? | 02895-67116 | O-RING (K1) | 2 | SN: 116563- |
|||
| ? | 6691-11-4490 | GASKET (K1) | 1 | SN: 116563- |
|||
| ? | 6655-12-4830 | GASKET (K1) | 1 | SN: 116563- |
|||
| ? | 02010-70525 | BOLT | 8 | SN: 116563- |
|||
| ? | 01602-00825 | WASHER,SPRING | 8 | SN: 116563- |
