| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (22J-60-12102) | TRAVEL MOTOR ASS'Y | 2 | SN: 10001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-01A0 ? 02A0 AND 03A0. | ||||||
| ? | FUPMV07B1005AS | • MOTOR ASS'Y | 1 | SN: 10001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-02A0 AND Y1651-03A0. | ||||||
| ? | FUMW007BA4736 | • • BODY ASS'Y (K3) | 1 | SN: 10001- |
|||
| ? | ☆ | • • BODY SUB ASS'Y (K4) | 1 | SN: 10001- |
|||
| ? | FUFZS209803 | • • SHAFT | 1 | SN: 10001- |
|||
| ? | ☆ | • • CYLINDER (K5) | 1 | SN: 10001- |
|||
| ? | ☆ | • • PLATE,VALVE (K5) | 1 | SN: 10001- |
|||
| ? | ☆ | • • PISTON (K5) | 7 | SN: 10001- |
|||
| ? | ☆ | • • SHOE (K5) | 7 | SN: 10001- |
|||
| ? | ☆ | • • HOLDER,SHOE (K5) | 1 | SN: 10001- |
|||
| ? | ☆ | • • HOLDER (K5) | 1 | SN: 10001- |
|||
| ? | FUFZD4736110 | • • PLATE,SWASH | 1 | SN: 10001- |
|||
| ? | ☆ | • • PISTON,CONTROL (K4) | 1 | SN: 10001- |
|||
| ? | ☆ | • • PIN (K5) | 3 | SN: 10001- |
|||
| ? | ☆ | • • SPRING (K5) | 1 | SN: 10001- |
|||
| ? | FUPS29-101000 | • • RETAINER (K5) | 2 | SN: 10001- |
|||
| ? | FU6004 | • • BEARING | 1 | SN: 10001- |
|||
| ? | FU6201 | • • BEARING (K3) | 1 | SN: 10001- |
|||
| ? | FUROG10590 | • • O-RING (K6) | 1 | SN: 10001- |
|||
| ? | FUROP690 | • • O-RING (K6) | 1 | SN: 10001- |
|||
| ? | ☆ | • • SEAL,OIL (K4 ?K6) | 1 | SN: 10001- |
|||
| ? | FUYB-15/32 | • • BALL | 2 | SN: 10001- |
|||
| ? | FURH-28 | • • RING,SNAP (K5) | 1 | SN: 10001- |
|||
| ? | FUFZS209830 | • • SCREW | 7 | SN: 10001- |
|||
| ? | FUPPS-W-5X12 | • • PIN,SPRING (K3) | 1 | SN: 10001- |
|||
| ? | FUPPH7-6X14 | • • PIN | 1 | SN: 10001- |
|||
| ? | FU1701538687 | • • PLUG (K4) | 1 | SN: 10001- |
