| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 705-41-07160 | PUMP ASS'Y,(SBR5 + 5) | 1 | SN: 10001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 AND Y1600-02A0. | ||||||
| ? | (★705-41-83230) | • BRACKET | 1 | SN: 10001- |
|||
| ? | (★705-40-83640) | • • BUSHING,PLANE (DRIVE SIDE) | 1 | SN: 10001- |
|||
| ? | (★705-40-83630) | • • BUSHING,PLANE (DRIVEN SIDE) | 1 | SN: 10001- |
|||
| ? | (★705-41-17F10) | • CASE,GEAR | 1 | SN: 10001- |
|||
| ? | (★705-40-83630) | • • BUSHING,PLANE (DRIVE SIDE) | 2 | SN: 10001- |
|||
| ? | (★705-40-83640) | • • BUSHING,PLANE (DRIVEN SIDE) | 2 | SN: 10001- |
|||
| ? | (★705-41-17J40) | • GEAR,DRIVE | 1 | SN: 10001- |
|||
| ? | (★705-41-17H10) | • GEAR,DRIVEN | 1 | SN: 10001- |
|||
| ? | (★705-40-80881) | • PLATE | 1 | SN: 10001- |
|||
| ? | (★705-40-83760) | • SEAL | 1 | SN: 10001- |
|||
| ? | (★705-40-83720) | • PLATE,SIDE | 2 | SN: 10001- |
|||
| ? | (★705-40-80760) | • SEAL,RING | 1 | SN: 10001- |
|||
| ? | (★04020-00514) | • PIN,DOWEL | 2 | SN: 10001- |
|||
| ? | 705-40-80870 | • PLATE | 1 | SN: 10001- |
|||
| ? | 705-40-80810 | • SEAL,OIL | 1 | SN: 10001- |
|||
| ? | 04065-03515 | • RING,SNAP | 1 | SN: 10001- |
