| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-23-7650 | BRACKET | 1 | SN: 17210-@ |
|||
| ? | 01011-81225 | BOLT | 6 | SN: 17971-@ |
|||
| ? | 01643-31232 | WASHER | 6 | SN: 17210-@ |
|||
| ? | 04020-00820 | PIN,DOWEL | 2 | SN: 17210-@ |
|||
| ? | 6162-74-5111 | TUBE,INJECTION ? NO.1 | 1 | SN: 18030-@ |
|||
| ? | 6162-74-5121 | TUBE,INJECTION ? NO.2 | 1 | SN: 18030-@ |
|||
| ? | 6162-74-5131 | TUBE,INJECTION ? NO.3 | 1 | SN: 18030-@ |
|||
| ? | 6162-74-5141 | TUBE,INJECTION ? NO.4 | 1 | SN: 18030-@ |
|||
| ? | 6162-74-5151 | TUBE,INJECTION ? NO.5 | 1 | SN: 18030-@ |
|||
| ? | 6162-74-5161 | TUBE,INJECTION ? NO.6 | 1 | SN: 18030-@ |
|||
| ? | 6162-74-5910 | RUBBER | 2 | SN: 18030-@ |
|||
| ? | 6162-74-5920 | CLAMP | 2 | SN: 18030-@ |
|||
| ? | 01010-80835 | BOLT | 4 | SN: 17971-@ |
|||
| ? | 01602-00825 | WASHER | 4 | SN: 17210-@ |
|||
| ? | 6162-74-5511 | BRACKET | 1 | SN: 18030-@ |
|||
| ? | 6206-11-4490 | SPACER | 1 | SN: 17210-@ |
|||
| ? | 01011-81035 | BOLT | 1 | SN: 17971-@ |
|||
| ? | 01640-21016 | WASHER | 1 | SN: 17210-@ |
|||
| ? | 6162-74-5520 | BRACKET | 1 | SN: 17210-@ |
|||
| ? | 01435-00845 | BOLT | 2 | SN: 17210-@ |
|||
| ? | 01643-30823 | WASHER | 2 | SN: 17210-@ |
|||
| ? | 6162-74-5530 | BRACKET | 3 | SN: 17210-@ |
|||
| ? | 6206-11-4490 | SPACER | 3 | SN: 17210-@ |
|||
| ? | 01435-00885 | BOLT | 3 | SN: 17210-@ |
|||
| ? | 6162-74-5550 | CLAMP | 14 | SN: 18030-@ |
|||
| ? | 01010-80630 | BOLT | 7 | SN: 17971-@ |
|||
| ? | 01602-00619 | WASHER | 7 | SN: 18030-@ |
|||
| ? | 6164-71-4910 | COVER | 6 | SN: 17210-@ |
|||
| ? | 6162-73-4820 | TUBE,OIL SUPPLY | 1 | SN: 17210-19527 |
|||
| ? | 6162-73-4810 | TUBE,DRAIN | 1 | SN: 17210-@ |
|||
| ? | 6212-65-8860 | ADAPTER | 1 | SN: 17210-19527 |
|||
| ? | 07211-50710 | NIPPLE | 1 | SN: 17210-19527 |
|||
| ? | 07005-01412 | GASKET (K2) | 1 | SN: 17210-19527 |
|||
| ? | 07005-01012 | GASKET (K2) | 1 | SN: 17210-19527 |
|||
| ? | 6164-71-5690 | NIPPLE | 1 | SN: 17210-@ |
|||
| ? | 07005-01412 | GASKET (K2) | 1 | SN: 17210-@ |
|||
| ? | 07213-51013 | CONNECTOR | 1 | SN: 17210-@ |
