| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-53-1012 | OIL PUMP ASS'Y | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-1210 | • BODY ASS'Y | 1 | SN: 11500-17961 |
|||
| ? | ☆ | • • BODY | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-1180 | • • BUSHING | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-1270 | • • SHAFT,DRIVEN | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-1100 | • COVER ASS'Y | 1 | SN: 11500-17961 |
|||
| ? | ☆ | • • COVER | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-1180 | • • BUSHING | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-1240 | • SHAFT,DRIVE | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-1510 | • GEAR,DRIVE | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-1250 | • GEAR ASS'Y,DRIVEN | 1 | SN: 11500-17961 |
|||
| ? | ☆ | • • GEAR,DRIVEN | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-1280 | • • BUSHING | 2 | SN: 11500-17961 |
|||
| ? | 6162-53-1290 | • BOLT | 2 | SN: 11500-17961 |
|||
| ? | 01051-31250 | • BOLT | 2 | SN: 11500-17961 |
|||
| ? | 01602-01236 | • WASHER,SPRING | 4 | SN: 11500-17961 |
|||
| ? | 01582-01210 | • NUT | 4 | SN: 11500-17961 |
|||
| ? | 6162-53-1651 | • PLUG | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-6852 | • PLUNGER ASS'Y | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-6862 | • • PLUNGER | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-6870 | • • BALL | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-6880 | • • SPRING | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-1190 | • • PIN | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-6890 | • SPRING | 1 | SN: 11500-17961 |
|||
| ? | 6110-25-6340 | • SHIM ASS'Y | 3 | SN: 11500-17961 |
|||
| ? | 01010-31240 | BOLT | 4 | SN: 11500-17961 |
|||
| ? | 01602-01236 | WASHER,SPRING | 4 | SN: 11500-17961 |
|||
| ? | 07000-62015 | O-RING (K2) | 1 | SN: 11500-17961 |
|||
| ? | 6162-53-6410 | PIPE | 1 | SN: 11500-17961 |
|||
| ? | 07000-E3042 | O-RING (K2) | 1 | SN: 16216-17961 |
|||
| ? | ♦6162-53-6370 | O-RING (K2) | 1 | SN: 11500-16215 |
|||
| ? | 6127-51-6822 | GASKET (K2) | 1 | SN: 16017-17961 |
|||
| ? | □6127-51-6821 | GASKET (K2) | 1 | SN: 11500-16016 |
|||
| ? | 01010-31070 | BOLT | 2 | SN: 11500-17961 |
|||
| ? | 01602-01030 | WASHER,SPRING | 2 | SN: 11500-17961 |
