| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-13-4111 | MANIFOLD,INTAKE | 1 | SN: 17210-@ |
|||
| ? | 6162-15-4670 | CONNECTOR | 1 | SN: 17210-@ |
|||
| ? | 6162-13-4141 | GASKET (K1) | 1 | SN: 17210-@ |
|||
| ? | 01435-00840 | BOLT | 34 | SN: 17210-@ |
|||
| ? | 6162-14-4910 | BOLT | 4 | SN: 17210-@ |
|||
| ? | 6162-65-6470 | COVER | 2 | SN: 17210-@ |
|||
| ? | 6162-63-6841 | GASKET (K1) | 2 | SN: 17210-@ |
|||
| ? | 01010-81030 | BOLT | 8 | SN: 17210-@ |
|||
| ? | 01640-21016 | WASHER | 8 | SN: 17210-@ |
|||
| ? | 07042-00108 | PLUG | 1 | SN: 17210-@ |
|||
| ? | 6162-13-4812 | GASKET (K1) | 1 | SN: 17210-@ |
|||
| ? | 01010-81095 | BOLT | 13 | SN: 17210-@ |
|||
| ? | 01011-81055 | BOLT | 18 | SN: 17210-@ |
|||
| ? | 01602-01030 | WASHER,SPRING | 31 | SN: 17210-@ |
|||
| ? | 01640-21016 | WASHER | 31 | SN: 17210-@ |
|||
| ? | 02720-21214 | PLUG | 1 | SN: 17210-@ |
|||
| ? | 6162-14-4710 | CONNECTOR | 1 | SN: 17210-@ |
|||
| ? | 02895-77091 | O-RING (K1) | 2 | SN: 17210-@ |
|||
| ? | 6710-11-4780 | PLATE | 2 | SN: 17210-@ |
|||
| ? | 01010-80820 | BOLT | 2 | SN: 17210-@ |
|||
| ? | 01602-00825 | WASHER,SPRING | 2 | SN: 17210-@ |
|||
| ? | 6162-14-4720 | TUBE | 1 | SN: 17210-@ |
|||
| ? | 6162-14-4780 | PLATE | 1 | SN: 17210-@ |
|||
| ? | 6162-14-4770 | PLATE | 2 | SN: 17210-@ |
|||
| ? | 01436-01015 | BOLT | 4 | SN: 17210-@ |
|||
| ? | 07283-21193 | CLIP | 2 | SN: 17210-@ |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 17210-@ |
|||
| ? | 01597-01211 | NUT | 4 | SN: 17210-@ |
|||
| ? | 6162-14-4790 | BRACKET | 1 | SN: 17210-@ |
|||
| ? | 01011-81005 | BOLT | 2 | SN: 17210-@ |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 17210-@ |
|||
| ? | 07283-21193 | CLIP | 1 | SN: 17210-@ |
|||
| ? | 01597-01211 | NUT | 2 | SN: 17210-@ |
|||
| ? | 6162-14-4760 | HOSE | 1 | SN: 17210-@ |
|||
| ? | 07289-00120 | CLAMP | 4 | SN: 17210-@ |
|||
| ? | 6162-14-4740 | CONNECTOR | 1 | SN: 17210-@ |
|||
| ? | 6162-15-4750 | GASKET (K1) | 1 | SN: 17210-@ |
|||
| ? | 01010-81235 | BOLT | 4 | SN: 17210-@ |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 17210-@ |
