| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 14Y-62-11111 | PIPE | 1 | Field_1: J10001-J10240 |
|||
| ? | 14Y-62-11112 | PIPE | 1 | Field_1: J10241-J11077 |
|||
| ? | 14Y-62-11113 | PIPE | 1 | Field_1: J11078- |
|||
| ? | 01010-81050 | BOLT | 4 | Field_1: J10001- |
|||
| ? | 01643-31032 | WASHER | 4 | Field_1: J10001- |
|||
| ? | 07000-02090 | O-RING | 1 | Field_1: J10001- |
|||
| ? | 07260-25818 | HOSE | 1 | Field_1: J10001- |
|||
| ? | 07281-00809 | CLAMP | 4 | Field_1: J10001- |
|||
| ? | 14Y-62-11122 | BRACKET | 1 | Field_1: J10001- |
|||
| ? | 01010-81225 | BOLT | 2 | Field_1: J10001- |
|||
| ? | 01643-31232 | WASHER | 2 | Field_1: J10001- |
|||
| ? | 07283-26155 | CLIP | 1 | Field_1: J10001- |
|||
| ? | 01599-01011 | NUT | 2 | Field_1: J10001- |
|||
| ? | 01643-31032 | WASHER | 2 | Field_1: J10001- |
|||
| ? | 14Y-62-11181 | PIPE | 1 | Field_1: J10001-J10240 |
|||
| ? | 14Y-62-11182 | PIPE | 1 | Field_1: J10241-J11077 |
|||
| ? | 14Y-62-11183 | PIPE | 1 | Field_1: J11078- |
|||
| ? | 14Y-62-11131 | HOSE | 1 | Field_1: J10001- |
|||
| ? | 07281-00809 | CLAMP | 4 | Field_1: J10001- |
|||
| ? | 14W-62-11190 | PIPE | 1 | Field_1: J10001-J10240 |
|||
| ? | 14W-62-11191 | PIPE | 1 | Field_1: J10241-J11077 |
|||
| ? | 14W-62-11192 | PIPE | 1 | Field_1: J11078- |
|||
| ? | 14X-62-11113 | PIPE | 1 | Field_1: J10001- |
|||
| ? | 01010-81245 | BOLT | 4 | Field_1: J10001- |
|||
| ? | 01643-51232 | WASHER | 4 | Field_1: J10001- |
|||
| ? | 07000-02060 | O-RING | 1 | Field_1: J10001- |
|||
| ? | 07283-26155 | CLIP | 1 | Field_1: J10001- |
|||
| ? | 01599-01011 | NUT | 2 | Field_1: J10001- |
|||
| ? | 01643-31032 | WASHER | 2 | Field_1: J10001- |
|||
| ? | 14W-62-11110 | HOSE | 1 | Field_1: J10001-J10063 |
|||
| ? | 14W-62-11111 | HOSE | 1 | Field_1: J10064- |
|||
| ? | 07371-31049 | FLANGE | 2 | Field_1: J10001- |
|||
| ? | 07372-21035 | BOLT | 4 | Field_1: J10001- |
|||
| ? | 01643-51032 | WASHER | 4 | Field_1: J10001- |
|||
| ? | 07000-13032 | O-RING | 1 | Field_1: J10001- |
|||
| ? | 07371-31225 | FLANGE | 2 | Field_1: J10001- |
|||
| ? | 01010-21035 | BOLT | 4 | Field_1: J10001- |
|||
| ? | 01643-51032 | WASHER | 4 | Field_1: J10001- |
|||
| ? | 07000-13038 | O-RING | 1 | Field_1: J10001- |
