| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | CU203176 | ALTERNATOR A. (50A) | 1 | SN: 113641- |
|||
| ? | CUDR-1892960 | • HOUSING ASS'Y | 1 | SN: 113641- |
|||
| ? | CUDR-1968913 | • • COVER | 1 | SN: .- |
|||
| ? | CUDR-1969671 | • • CLIP | 1 | SN: 113641-. |
|||
| ? | CUDR-9436064 | • • BEARING | 1 | SN: 113641- |
|||
| ? | CUDR-1968990 | • • BUSHING | 1 | SN: 113641- |
|||
| ? | CUDR-1966554 | • • SEAL | 1 | SN: 113641- |
|||
| ? | CUDR-1971671 | • • RESISTOR | 3 | SN: 113641- |
|||
| ? | CUDR-9427882 | • • PLUG | 1 | SN: 113641- |
|||
| ? | CUDR-1968904 | • • ROTOR | 1 | SN: 113641- |
|||
| ? | CUDR-1971465 | • STATOR ASS'Y | 1 | SN: 113641- |
|||
| ? | CUDR-1969671 | • • CLIP | 1 | SN: 113641- |
|||
| ? | CUDR-1968900 | • • GROMMET | 1 | SN: 113641- |
|||
| ? | CUDR-1968901 | • • INSULATOR | 1 | SN: 113641- |
|||
| ? | CUDR-1852726 | • • FRAME | 1 | SN: 113641- |
|||
| ? | CUDR-1958509 | • SEAL | 1 | SN: 113641- |
|||
| ? | CUDR-908055 | • BEARING | 1 | SN: 113641- |
|||
| ? | CUDR-1970407 | • RETAINER ASS'Y | 1 | SN: 113641- |
|||
| ? | CUDR-1958509 | • • SEAL | 1 | SN: 113641- |
|||
| ? | CUDR-1968885 | • COLLAR | 1 | SN: 113641- |
|||
| ? | CUDR-1968884 | • GASKET | 1 | SN: 113641- |
|||
| ? | CUDR-1968994 | • SCREW | 4 | SN: 113641- |
|||
| ? | CUDR-1969133 | • COIL | 1 | SN: 113641- |
|||
| ? | CUDR-9436063 | • BEARING | 1 | SN: 113641- |
|||
| ? | CUDR-1968991 | • BOLT | 4 | SN: 113641- |
|||
| ? | CUDR-1969481 | • FAN | 1 | SN: 113641- |
|||
| ? | CUDR-1968890 | • COLLAR | 1 | SN: 113641- |
|||
| ? | CUDR-1968891 | • SLINGER | 1 | SN: 113641- |
|||
| ? | CUDR-9418881 | • NUT | 1 | SN: 113641- |
|||
| ? | CUDR-1905406 | • WASHER | 1 | SN: 113641- |
|||
| ? | CUDR-1971670 | • HEAT SINK ASS'Y | 1 | SN: 113641- |
|||
| ? | CUDR-1971675 | • • STUD | 1 | SN: 113641- |
|||
| ? | CUDR-1971672 | • • RESISTOR | 3 | SN: 113641- |
|||
| ? | CUDR-1968930 | • INSULATOR | 1 | SN: 113641- |
|||
| ? | CUDR-453996 | • NUT | 1 | SN: 113641- |
|||
| ? | CUDR-1970397 | • SCREW | 4 | SN: 113641- |
|||
| ? | CUDR-1971674 | • TERMINAL | 1 | SN: 113641- |
|||
| ? | CUDR-1969002 | • TERMINAL | 1 | SN: 113641- |
|||
| ? | CUDR-1968945 | • SCREW | 3 | SN: 113641- |
|||
| ? | CUDR-1968940 | • SCREW | 1 | SN: 113641- |
|||
| ? | CUDR-453844 | • WASHER | 1 | SN: 113641- |
|||
| ? | CUDR-815540 | • WASHER | 1 | SN: 113641- |
|||
| ? | CUDR-1959389 | • INSULATOR | 1 | SN: 113641- |
|||
| ? | CUDR-1971673 | • TERMINAL | 1 | SN: 113641- |
|||
| ? | CUDR-1968988 | • LEAD | 1 | SN: 113641- |
|||
| ? | CUDR-1892824 | • REGULATOR | 1 | SN: 113641- |
|||
| ? | CUDR-1961570 | • SCREW | 2 | SN: 113641- |
|||
| ? | CUDR-9416003 | • WASHER | 2 | SN: 113641- |
|||
| ? | CUDR-1970397 | • SCREW | 2 | SN: 113641- |
|||
| ? | CUDR-453844 | • WASHER | 2 | SN: 113641- |
|||
| ? | CUDR-9427129 | • SCREW | 2 | SN: 113641- |
|||
| ? | CUDR-9421423 | • WASHER | 2 | SN: 113641- |
|||
| ? | CUDR-1969000 | • COVER | 1 | SN: 113641- |
|||
| ? | CUDR-1970395 | • GASKET | 1 | SN: 113641- |
|||
| ? | CUDR-1846957 | • SCREW | 2 | SN: 113641- |
|||
| ? | CUDR-1846956 | • SCREW | 2 | SN: 113641- |
|||
| ? | CUDR-453435 | • WASHER | 4 | SN: 113641- |
|||
| ? | CUDR-1969001 | • PLATE | 1 | SN: 113641- |
|||
| ? | CUDR-1846955 | • SCREW | 4 | SN: 113641- |
|||
| ? | CUDR-453844 | • WASHER | 4 | SN: 113641- |
|||
| ? | CUDR-1968996 | • GROMMET | 1 | SN: 113641- |
|||
| ? | CUDR-9416005 | • WASHER,(NOT SHOWN) | 1 | SN: 113641- |
|||
| ? | CUDR-1882267 | • WASHER,(NOT SHOWN) | 1 | SN: 113641- |
|||
| ? | CUDR-1970227 | • CAP,(NOT SHOWN) | 1 | SN: 113641- |
|||
| ? | CUDR-1846938 | • SUPPORT,(NOT SHOWN) | 1 | SN: 113641- |
