| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | CU166468 | CONNECTOR | 1 | SN: 117097- |
|||
| ? | CU157911 | GASKET | 1 | SN: 117097- |
|||
| ? | CUS-134 | BOLT | 2 | SN: 117097- |
|||
| ? | 02310-01020 | WASHER,SPRING | 2 | SN: 117097- |
|||
| ? | 02300-01120 | WASHER | 2 | SN: 117097- |
|||
| ? | CU217302 | HOSE | 1 | SN: 117097- |
|||
| ? | CU3010518 | CLAMP | 2 | SN: 117097- |
|||
| ? | CU3012304 | CONNECTOR | 1 | SN: 117097- |
|||
| ? | CU207038 | O-RING | 1 | SN: 117097- |
|||
| ? | CUS-103-D | BOLT | 2 | SN: 117097- |
|||
| ? | 02310-11224 | WASHER,SPRING | 2 | SN: 117097- |
|||
| ? | 6710-91-2810 | FITTING | 2 | SN: 117097- |
|||
| ? | CU3200063 | TUBE | 1 | SN: 117097- |
|||
| ? | CU3200377 | TUBE | 1 | SN: 117097- |
|||
| ? | CU206940 | HOSE | 1 | SN: 117097- |
|||
| ? | CU43828 | CLAMP | 2 | SN: 117097- |
|||
| ? | CUAR-12075 | TUBE ASS'Y | 1 | SN: 117097- |
|||
| ? | ☆ | • FLANGE | 1 | SN: 117097- |
|||
| ? | ☆ | • TUBE | 1 | SN: 117097- |
|||
| ? | CU207117 | GASKET | 1 | SN: 117097- |
|||
| ? | CUS-112 | BOLT | 2 | SN: 117097- |
|||
| ? | 02310-01224 | WASHER,SPRING | 2 | SN: 117097- |
