| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | SERIALNO: |
|||||
| ? | (714-21-10005) | TRANSMISSION ASS'Y | 1 | SN: (1490)- KIT-FLAG: _- SERIALNO: (1490)- |
|||
| ? | (☒714-21-10004) | TRANSMISSION ASS'Y | 1 | SN: ((1490)-00053227) KIT-FLAG: _- SERIALNO: ((1490)-00053227) |
|||
| ? | (☒714-21-10003) | TRANSMISSION ASS'Y | 1 | SN: ((1490)-(101557)) KIT-FLAG: _- SERIALNO: ((1490)-(101557)) |
|||
| ? | □714-21-10002 | TRANSMISSION ASS'Y | 1 | SN: (1224)-(1489) KIT-FLAG: _- SERIALNO: (1224)-(1489) |
|||
| ? | THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0. | SERIALNO: |
|||||
| ? | 714-22-15011 | • VALVE ASS'Y | 1 | SN: (1490)- KIT-FLAG: _- SERIALNO: (1490)- |
|||
| ? | □714-22-15010 | • VALVE ASS'Y,T/M ASS'Y | 1 | SN: (1456)-00053227 KIT-FLAG: _- SERIALNO: (1456)-00053227 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-62A0A AND F4350-63A0. | SERIALNO: |
|||||
| ? | 714-22-15200 | • • VALVE ASS'Y,UPPER ASS'Y | 1 | SN: (1456)- KIT-FLAG: _- SERIALNO: (1456)- |
|||
| ? | 714-22-00030 | • • • BODY ASS'Y,UPPER | 1 | SN: (1456)- KIT-FLAG: _- SERIALNO: (1456)- |
|||
| ? | 714-22-15110 | • • • • BODY,UPPER | 1 | SN: (1456)- KIT-FLAG: _- SERIALNO: (1456)- |
|||
| ? | 714-07-15450 | • • • • ORIFICE | 2 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 07043-70108 | • • • • PLUG | 1 | SN: (1368)- KIT-FLAG: _- SERIALNO: (1368)- |
|||
| ? | 714-22-15810 | • • • COVER,UPPER R | 1 | SN: (1456)- KIT-FLAG: _- SERIALNO: (1456)- |
|||
| ? | 714-19-15820 | • • • COVER,UPPER L | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 714-19-15930 | • • • GASKET,UPPER R (K2) | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 714-19-15940 | • • • GASKET,UPPER L (K2) | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 714-19-15310 | • • • VALVE,PRIORITY | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 198-15-15760 | • • • VALVE | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 561-13-46850 | • • • PISTON | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 198-15-15770 | • • • SPRING, (L= 30.0) | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 714-19-16110 | • • • SPRING | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 714-19-15231 | • • • VALVE,MAIN | 1 | SN: (1425)- KIT-FLAG: _- SERIALNO: (1425)- |
|||
| ? | 198-15-15760 | • • • VALVE | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 561-13-46850 | • • • PISTON | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 198-15-15770 | • • • SPRING, (L= 30.0) | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 714-19-16150 | • • • SPRING | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 714-19-15220 | • • • SPACER | 1 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 714-19-15430 | • • • VALVE,MODULATE | 2 | SN: (1425)- KIT-FLAG: _- SERIALNO: (1425)- |
|||
| ? | 714-19-15420 | • • • PISTON | 2 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 714-07-15570 | • • • SPRING,MODULATE | 2 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 01010-80850 | • • • BOLT | 2 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 01010-80830 | • • • BOLT | 11 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 714-22-18450 | • • • BRACKET | 1 | SN: (1456)- KIT-FLAG: _- SERIALNO: (1456)- |
|||
| ? | 01010-80835 | • • • BOLT | 2 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 01643-30823 | • • • WASHER | 2 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 569-15-45610 | • • • SOLENOID VALVE | 2 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 01252-40625 | • • • BOLT | 8 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 07000-73035 | • • • O-RING (K2) | 2 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
|||
| ? | 07042-30108 | • • • PLUG | 8 | SN: 53001- KIT-FLAG: _- SERIALNO: 53001- |
