| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 258-51-23103 | FRAME | 1 | SN: 2701- |
|||
| ? | 258-10-23801 | BRACKET | 1 | SN: 2001- |
|||
| ? | 258-10-23911 | PLATE | 1 | SN: 2001- |
|||
| ? | 258-10-14710 | COVER | 1 | SN: 2001- |
|||
| ? | 258-10-14600 | GASKET | 1 | SN: 2001- |
|||
| ? | 258-10-13940 | BRACKET | 2 | SN: 2001- |
|||
| ? | 258-10-13930 | CUSHION | 4 | SN: 2001- |
|||
| ? | 268-30-16680 | BALL | 1 | SN: 2001- |
|||
| ? | 258-10-23700 | ROD | 1 | SN: 2001- |
|||
| ? | 257-10-15620 | HINGE | 2 | SN: 2001- |
|||
| ? | 01010-30816 | BOLT | 24 | SN: 2001- |
|||
| ? | 01602-20825 | WASHER,SPRING | 11 | SN: 2001- |
|||
| ? | 01640-20816 | WASHER | 8 | SN: 2001- |
|||
| ? | 01580-30605 | NUT | 6 | SN: 2001- |
|||
| ? | 01602-20619 | WASHER,SPRING | 6 | SN: 2001- |
|||
| ? | 01580-30806 | NUT | 2 | SN: 2001- |
|||
| ? | 2691-6-13420 | WASHER | 2 | SN: 2001- |
|||
| ? | 258-10-25612 | COVER | 1 | SN: 2701- |
|||
| ? | 258-10-24800 | COVER | 1 | SN: 2001- |
|||
| ? | 258-10-27620 | STAY | 2 | SN: 2001- |
|||
| ? | 257-10-17630 | MIRROR | 2 | SN: 2001- |
|||
| ? | 01580-21210 | NUT | 4 | SN: 2001- |
|||
| ? | 258-10-23950 | COVER | 2 | SN: 2001- |
|||
| ? | 258-10-25714 | COVER | 1 | SN: 2701- |
|||
| ? | 01010-30816 | BOLT | 8 | SN: 2001- |
|||
| ? | 01602-20825 | WASHER,SPRING | 8 | SN: 2001- |
|||
| ? | 01010-31025 | BOLT | 4 | SN: 2001- |
|||
| ? | 01602-21030 | WASHER,SPRING | 4 | SN: 2701- |
|||
| ? | 01580-31008 | NUT | 4 | SN: 2001- |
|||
| ? | 01010-30820 | BOLT | 2 | SN: 2001- |
|||
| ? | 01010-30816 | BOLT | 2 | SN: 2001- |
|||
| ? | 01602-20825 | WASHER,SPRING | 4 | SN: 2001- |
|||
| ? | 258-10-25105 | DASHBOARD | 1 | SN: 2701- |
|||
| ? | 01010-31025 | BOLT | 4 | SN: 2001- |
|||
| ? | 01580-11008 | NUT | 4 | SN: 2001- |
|||
| ? | 01602-21030 | WASHER,SPRING | 4 | SN: 2001- |
