| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6162-73-2352) | INJECTION PUMP A. | 1 | SN: 19362- |
|||
| ? | (□6162-73-2351) | INJECTION PUMP A. | 1 | SN: 18632-19361 |
|||
| ? | (□6162-73-2350) | INJECTION PUMP A. | 1 | SN: 17059-18631 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B6G6 T0 A4010-G6G6. | ||||||
| ? | DK105235-1821 | • FEED PUMP ASS'Y | 1 | SN: 18632- |
|||
| ? | DK105235-1751 | • FEED PUMP ASS'Y | 1 | SN: 17059-18631 |
|||
| ? | DK152002-2220 | • • HOUSING | 1 | SN: 17059- |
|||
| ? | DK152100-1120 | • • PISTON | 1 | SN: 17059- |
|||
| ? | DK152104-0400 | • • SPRING,PISTON | 1 | SN: 17059- |
|||
| ? | DK152105-1500 | • • PLUG | 1 | SN: 17059- |
|||
| ? | DK152111-4620 | • • TAPPET ASS'Y | 1 | SN: 17059- |
|||
| ? | DK152112-0800 | • • • ROLLER | 1 | SN: 17059- |
|||
| ? | DK152113-1300 | • • • PIN | 1 | SN: 17059- |
|||
| ? | DK152114-1600 | • • • GUIDE | 2 | SN: 17059- |
|||
| ? | DK152115-0500 | • • VALVE | 4 | SN: 17059- |
|||
| ? | DK152116-0200 | • • SPRING | 4 | SN: 17059- |
|||
| ? | DK152117-0400 | • • PLUG | 3 | SN: 17059- |
|||
| ? | DK029631-6060 | • • O-RING | 1 | SN: 17059- |
|||
| ? | DK152121-0200 | • • RING,SNAP | 1 | SN: 17059- |
|||
| ? | DK152200-5320 | • • PUMP,PRIMING | 1 | SN: 17059- |
|||
| ? | DK152300-4020 | • • BOLT,EYE | 1 | SN: 17059- |
|||
| ? | DK029731-4680 | • • BOLT,EYE | 1 | SN: 17059- |
|||
| ? | DK029711-4430 | • • EYE | 1 | SN: 17059-18631 |
|||
| ? | DK029341-4130 | • • GASKET | 5 | SN: 17059- |
|||
| ? | DK132400-0200 | • • ADAPTER | 2 | SN: 17059- |
|||
| ? | DK152320-0100 | • • COVER | 1 | SN: 17059- |
