| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6162-73-1755) | INJECTION PUMP A. | 1 | SN: 19362- |
|||
| ? | (□6162-73-1754) | INJECTION PUMP A. | 1 | SN: 18632-19361 |
|||
| ? | (□6162-73-1753) | INJECTION PUMP A. | 1 | SN: 15308-18631 |
|||
| ? | (□6162-73-1752) | INJECTION PUMP A. | 1 | SN: 13474-15307 |
|||
| ? | (☒6162-73-1751) | INJECTION PUMP A. | 1 | SN: (13474-13829) |
|||
| ? | (□6162-73-1750) | INJECTION PUMP A. | 1 | SN: 11500-13473 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B6C6 T0 A4010-G6C6. | ||||||
| ? | DK105445-0793 | • GOVERNOR ASS'Y | 1 | SN: 19362- |
|||
| ? | DK105445-0792 | • GOVERNOR ASS'Y | 1 | SN: 18632-19361 |
|||
| ? | DK105445-0791 | • GOVERNOR ASS'Y | 1 | SN: 15308-18631 |
|||
| ? | DK105445-0790 | • GOVERNOR ASS'Y | 1 | SN: 13830-15307 |
|||
| ? | DK105445-0521 | • GOVERNOR ASS'Y | 1 | SN: 13474-13829 |
|||
| ? | DK105445-0520 | • GOVERNOR ASS'Y | 1 | SN: 11500-13473 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-D6C6 AND A4010-E6C6. | ||||||
| ? | DK154003-2020 | • • HOUSING | 1 | SN: 13830- |
|||
| ? | DK154003-1520 | • • HOUSING | 1 | SN: 11500-13829 |
|||
| ? | DK154007-3400 | • • PLUG | 1 | SN: 13830- |
|||
| ? | DK154007-1400 | • • PLUG | 1 | SN: 11500-13829 |
|||
| ? | DK154007-0500 | • • ADAPTER | 1 | SN: 11500- |
|||
| ? | DK010038-1840 | • • BOLT | 1 | SN: 13830- |
|||
| ? | DK010008-1840 | • • BOLT | 1 | SN: 11500-13829 |
|||
| ? | DK014110-8440 | • • WASHER,SPRING | 1 | SN: 11500- |
|||
| ? | DK020018-2840 | • • BOLT | 10 | SN: 13830- |
|||
| ? | DK010008-2840 | • • BOLT | 10 | SN: 11500-13829 |
|||
| ? | DK014110-8440 | • • WASHER,SPRING | 10 | SN: 11500-13829 |
|||
| ? | DK154010-9500 | • • SCREW | 1 | SN: 13474- |
|||
| ? | DK154034-2100 | • • BOLT | 1 | SN: 11500-13473 |
|||
| ? | DK029241-0020 | • • NUT | 2 | SN: 11500- |
|||
| ? | DK154010-9800 | • • BOLT | 1 | SN: 13474- |
|||
| ? | DK154034-0400 | • • BOLT | 1 | SN: 11500-13473 |
|||
| ? | DK154050-1620 | • • LIMITER | 1 | SN: 11500- |
|||
| ? | DK154102-2420 | • • FLYWEIGHT ASS'Y | 1 | SN: 11500- |
|||
| ? | DK025804-1610 | • • KEY | 1 | SN: 11500- |
|||
| ? | DK029321-4010 | • • WASHER,SPRING | 1 | SN: 11500- |
|||
| ? | DK131325-2600 | • • NUT | 1 | SN: 11500- |
|||
| ? | DK154120-0200 | • • WASHER | 1 | SN: 11500- |
|||
| ? | DK016020-2510 | • • RING,SNAP | 1 | SN: 11500- |
|||
| ? | DK154121-0900 | • • GEAR | 1 | SN: 11500- |
|||
| ? | DK016630-2640 | • • BEARING | 1 | SN: 11500- |
|||
| ? | DK028102-5010 | • • BEARING | 1 | SN: 11500- |
|||
| ? | DK029313-2010 | • • SHIM | 1 | SN: 11500- |
|||
| ? | DK029313-2020 | • • SHIM | 1 | SN: 11500- |
|||
| ? | DK154122-0200 | • • COVER | 1 | SN: 11500- |
|||
| ? | DK016110-5210 | • • RING,SNAP | 1 | SN: 11500- |
|||
| ? | DK025805-1910 | • • KEY | 1 | SN: 11500- |
|||
| ? | DK023641-8410 | • • WASHER,SPRING | 1 | SN: 11500- |
|||
| ? | DK154011-2400 | • • NUT | 1 | SN: 11500- |
|||
| ? | DK154123-1820 | • • SLEEVE | 1 | SN: 11500- |
|||
| ? | DK029311-5020 | • • SHIM ? 0.05MM | A/R | SN: 11500- |
|||
| ? | DK029311-5030 | • • SHIM ? 0.1MM | A/R | SN: 11500- |
|||
| ? | DK029311-5050 | • • SHIM ? 0.2MM | A/R | SN: 11500- |
|||
| ? | DK029311-5120 | • • SHIM ? 0.3MM | A/R | SN: 11500- |
|||
| ? | DK029311-5060 | • • SHIM ? 0.4MM | A/R | SN: 11500- |
|||
| ? | DK029311-5080 | • • SHIM ? 0.5MM | A/R | SN: 11500- |
|||
| ? | DK154130-2320 | • • GEAR ASS'Y | 1 | SN: 11500- |
|||
| ? | DK015325-1590 | • • PIN,SPLIT | 1 | SN: 11500- |
|||
| ? | DK029310-6040 | • • SHIM | 1 | SN: 11500- |
|||
| ? | DK154356-6000 | • • PIN | 1 | SN: 11500- |
|||
| ? | DK154154-2300 | • • SPRING | 1 | SN: 11500- |
|||
| ? | DK154187-0120 | • • CAPSULE,SPRING | 1 | SN: 11500- |
|||
| ? | DK139220-0400 | • • NUT | 1 | SN: 13474- |
|||
| ? | DK139220-0300 | • • NUT | 1 | SN: 11500-13473 |
|||
| ? | DK154008-0200 | • • WASHER,LOCK | 1 | SN: 11500-13473 |
|||
| ? | DK154217-6020 | • • GUIDE LEVER ASS'Y,GUIDE | 1 | SN: 13830- |
|||
| ? | DK154216-6720 | • • LEVER,GUIDE | 1 | SN: 11500-13829 |
|||
| ? | DK154234-0920 | • • LINK | 1 | SN: 11500- |
|||
| ? | DK154232-0100 | • • CONNECTOR | 1 | SN: 11500- |
|||
| ? | DK010006-1840 | • • BOLT | 1 | SN: 11500- |
|||
| ? | DK013020-6040 | • • NUT | 1 | SN: 11500- |
|||
| ? | DK154233-0100 | • • WASHER,LOCK | 2 | SN: 11500- |
|||
| ? | DK153400-0200 | • • SEAT,SPRING | 1 | SN: 11500- |
|||
| ? | DK153401-0300 | • • SPRING | 1 | SN: 11500- |
|||
| ? | DK154236-8100 | • • LEVER,TENSION | 1 | SN: 11500- |
|||
| ? | DK154333-0200 | • • LEVER | 1 | SN: 11500- |
|||
| ? | DK154334-0100 | • • PIN | 1 | SN: 11500- |
|||
| ? | DK029301-0030 | • • WASHER | 2 | SN: 11500- |
|||
| ? | DK029300-8070 | • • WASHER | 1 | SN: 11500- |
|||
| ? | DK013020-8020 | • • NUT | 1 | SN: 11500- |
|||
| ? | DK025520-1210 | • • PIN,SPLIT | 1 | SN: 11500- |
|||
| ? | DK154335-0100 | • • SEAT,SPRING | 1 | SN: 11500- |
|||
| ? | DK154336-0100 | • • SPRING | 1 | SN: 11500- |
|||
| ? | DK154336-0200 | • • SPRING | 1 | SN: 11500- |
|||
| ? | DK154337-0100 | • • PLUG | 1 | SN: 11500- |
|||
| ? | DK154390-3000 | • • GASKET | 1 | SN: 18632- |
|||
| ? | DK153550-3100 | • • GASKET | 1 | SN: 11500-18631 |
