| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-33-2140 | PISTON | 6 | SN: 14020- |
|||
| ? | 6162-33-2110 | PISTON | 6 | SN: 11500-14019 |
|||
| ? | 6162-33-2410 | PIN,PISTON | 6 | SN: 11500- |
|||
| ? | 6162-33-2420 | RING,SNAP | 12 | SN: 11500- |
|||
| ? | 6162-33-2060 | PISTON RING ASS'Y,PER CYLINDER | 6 | SN: 11500- |
|||
| ? | ☆ | • RING,TOP | 1 | SN: 11500- |
|||
| ? | ☆ | • RING,SECOND | 1 | SN: 11500- |
|||
| ? | ☆ | • RING,OIL | 1 | SN: 11500- |
|||
| ? | 6162-33-3101 | CONNECTING ROD ASS'Y | 6 | SN: 11500- |
|||
| ? | ☆ | • ROD,CONNECTING | 1 | SN: 11500- |
|||
| ? | ☆ | • CAP,CONNECTING | 1 | SN: 11500- |
|||
| ? | 6162-33-3131 | • BUSHING | 1 | SN: 11500- |
|||
| ? | 02400-10413 | • PIN,DOWEL | 4 | SN: 11500- |
|||
| ? | 6162-33-3310 | • BOLT | 2 | SN: 11500- |
|||
| ? | 6162-33-3330 | • WASHER | 2 | SN: 11500- |
|||
| ? | STANDARD | ||||||
| ? | 6162-33-3041 | METAL ASS'Y | 6 | SN: 13113- |
|||
| ? | □6162-33-3040 | METAL ASS'Y | 6 | SN: 11500-13112 |
|||
| ? | ☆ | • METAL | 2 | SN: 13113- |
|||
| ? | ☆ | • METAL | 2 | SN: 11500-13112 |
|||
| ? | UNDERSIZE 0.25MM | ||||||
| ? | 6162-39-3041 | METAL ASS'Y | 6 | SN: 13113- |
|||
| ? | □6162-39-3040 | METAL ASS'Y | 6 | SN: 11500-13112 |
|||
| ? | ☆ | • METAL | 2 | SN: 13113- |
|||
| ? | ☆ | • METAL | 2 | SN: 11500-13112 |
|||
| ? | UNDERSIZE 0.50MM | ||||||
| ? | 6162-38-3041 | METAL ASS'Y | 6 | SN: 13113- |
|||
| ? | □6162-38-3040 | METAL ASS'Y | 6 | SN: 11500-13112 |
|||
| ? | ☆ | • METAL | 2 | SN: 13113- |
|||
| ? | ☆ | • METAL | 2 | SN: 11500-13112 |
|||
| ? | UNDERSIZE 0.75MM | ||||||
| ? | 6162-37-3041 | METAL ASS'Y | 6 | SN: 13113- |
|||
| ? | □6162-37-3040 | METAL ASS'Y | 6 | SN: 11500-13112 |
|||
| ? | ☆ | • METAL | 2 | SN: 13113- |
|||
| ? | ☆ | • METAL | 2 | SN: 11500-13112 |
|||
| ? | UNDERSIZE 1.00MM | ||||||
| ? | 6162-36-3041 | METAL ASS'Y | 6 | SN: 13113- |
|||
| ? | □6162-36-3040 | METAL ASS'Y | 6 | SN: 11500-13112 |
|||
| ? | ☆ | • METAL | 2 | SN: 13113- |
|||
| ? | ☆ | • METAL | 2 | SN: 11500-13112 |
