| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-23-1103 | CYLINDER BLOCK ASS'Y | 1 | SN: 11500- |
|||
| ? | (☒6162-23-1102) | CYLINDER BLOCK ASS'Y | 1 | SN: (11500-13411) |
|||
| ? | ☆ | • BLOCK,CYLINDER | 1 | SN: 13412- |
|||
| ? | ☆ | • BLOCK,CYLINDER | 1 | SN: 11500-13411 |
|||
| ? | 6162-23-1490 | • BUSHING,CAM | 7 | SN: 11500- |
|||
| ? | \5\6162-29-1210 | • CAP,MAIN METAL ? NO.1 ?2 ?3 ?4 ?5 ?7 | 6 | SN: 11500- |
|||
| ? | \5\6162-29-1250 | • CAP,MAIN METAL ? NO.6 | 1 | SN: 11500- |
|||
| ? | 6162-23-1260 | • PIN,DOWEL | 2 | SN: 11500- |
|||
| ? | 6162-23-1710 | • BOLT,MAIN CAP | 14 | SN: 11500- |
|||
| ? | 6127-21-1741 | • WASHER | 14 | SN: 11500- |
|||
| ? | 04020-00514 | • PIN,DOWEL | 2 | SN: 11500- |
|||
| ? | 07043-50415 | • PLUG | 2 | SN: 11500- |
|||
| ? | 07046-23516 | • PLUG | 2 | SN: 11500- |
|||
| ? | 07043-50211 | • PLUG | 1 | SN: 11500- |
|||
| ? | 07043-50108 | • PLUG,(FOR SHIPPING) | 1 | SN: 11500- |
|||
| ? | 07043-50108 | • PLUG | 18 | SN: 11500- |
|||
| ? | 07042-A0108 | • PLUG | 2 | SN: 17363- |
|||
| ? | ♦07043-00108 | • PLUG | 2 | SN: 11500-17362 |
|||
| ? | 07046-28020 | • PLUG | 1 | SN: 11500- |
|||
| ? | 07040-11409 | • PLUG | 2 | SN: 11500- |
|||
| ? | 07005-01412 | • GASKET | 2 | SN: 11500- |
|||
| ? | 07040-11007 | • PLUG | 1 | SN: 11500- |
|||
| ? | 07005-01012 | • GASKET | 1 | SN: 11500- |
|||
| ? | 04020-01434 | • PIN,DOWEL | 2 | SN: 11500- |
|||
| ? | 6127-21-1160 | • PIN,DOWEL | 2 | SN: 11500- |
|||
| ? | 6162-13-1410 | • PIN | 12 | SN: 11500- |
|||
| ? | 6162-23-1140 | • TUBE,OIL TRANSFER | 1 | SN: 11500- |
|||
| ? | 04020-00820 | • PIN,DOWEL | 4 | SN: 11500- |
|||
| ? | 6162-25-2210 | LINER,CYLINDER | 6 | SN: 19579- |
|||
| ? | ♦6162-23-2210 | LINER,CYLINDER | 6 | SN: 11500-19578 |
|||
| ? | 6162-23-2250 | SEAL,CLEVIS | 6 | SN: 11500- |
|||
| ? | 6162-23-2220 | O-RING,CENTER | 6 | SN: 11500- |
|||
| ? | 6162-23-2240 | O-RING,LOWER | 6 | SN: 11500- |
|||
| ? | 6162-23-1860 | NOZZLE,PISTON COOLING | 1 | SN: 11500- |
|||
| ? | 6100-21-1130 | PLUG | 1 | SN: 11500- |
|||
| ? | 6162-23-1870 | NOZZLE,PISTON COOLING | 5 | SN: 11500- |
|||
| ? | 07000-72016 | O-RING | 6 | SN: 20263- |
|||
| ? | □07000-62016 | O-RING | 6 | SN: 11500-20262 |
|||
| ? | 01010-80818 | BOLT | 6 | SN: 11500- |
|||
| ? | 01602-00825 | WASHER,SPRING | 6 | SN: 11500- |
|||
| ? | 6162-29-2210 | SHIM ? 0.16MM,(REPAIR PARTS) | A/R | SN: 11500- |
|||
| ? | 6162-29-2220 | SHIM ? 0.20MM,(REPAIR PARTS) | A/R | SN: 11500- |
|||
| ? | 6162-29-2230 | SHIM ? 0.26MM,(REPAIR PARTS) | A/R | SN: 11500- |
|||
| ? | 6162-29-2240 | SHIM ? 0.50MM,(REPAIR PARTS) | A/R | SN: 11500- |
|||
| ? | 6162-29-2250 | SHIM ? 0.80MM,(REPAIR PARTS) | A/R | SN: 11500- |
|||
| ? | 6162-29-2260 | SHIM ? 1.50MM,(REPAIR PARTS) | A/R | SN: 11500- |
