| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-63-1015 | WATER PUMP ASS'Y | 1 | SN: 17712-@ |
|||
| ? | ☆ | • BODY | 1 | SN: 17712-@ |
|||
| ? | 6162-63-1570 | • SEAL,OIL | 1 | SN: 17712-@ |
|||
| ? | 06000-06205 | • BEARING,BALL | 1 | SN: 17712-@ |
|||
| ? | 06000-06306 | • BEARING,BALL | 1 | SN: 17712-@ |
|||
| ? | 6162-63-1340 | • RING,RETAINER | 1 | SN: 17712-@ |
|||
| ? | 6162-63-1514 | • SEAL ? WATER | 1 | SN: 17712-@ |
|||
| ? | 6162-63-1301 | • SHAFT ASS'Y | 1 | SN: 17712-@ |
|||
| ? | ☆ | • • SHAFT | 1 | SN: 17712-@ |
|||
| ? | ☆ | • • SHAFT | 1 | SN: 17712-@ |
|||
| ? | 6162-63-1353 | • IMPELLER | 1 | SN: 17712-@ |
|||
| ? | 6162-63-1180 | • HOUSING | 1 | SN: 17712-@ |
|||
| ? | 07000-72012 | • O-RING | 1 | SN: 17712-@ |
|||
| ? | 07000-05145 | • O-RING | 1 | SN: 17712-@ |
|||
| ? | 01010-81030 | • BOLT | 3 | SN: 17712-@ |
|||
| ? | 01010-81080 | • BOLT | 1 | SN: 17712-@ |
|||
| ? | 01602-01030 | • WASHER,SPRING | 4 | SN: 17712-@ |
|||
| ? | 01640-01016 | • WASHER | 4 | SN: 17712-@ |
|||
| ? | 6162-63-1440 | • RING,SNAP | 1 | SN: 17712-@ |
|||
| ? | 07043-70108 | • PLUG | 1 | SN: 17712-@ |
|||
| ? | 01010-81030 | BOLT | 2 | SN: 17712-@ |
|||
| ? | 01010-81270 | BOLT | 2 | SN: 17712-@ |
|||
| ? | 01010-81075 | BOLT | 1 | SN: 17712-@ |
|||
| ? | 01602-01030 | WASHER,SPRING | 3 | SN: 17712-@ |
|||
| ? | 01602-01236 | WASHER,SPRING | 2 | SN: 17712-@ |
|||
| ? | 6162-63-1531 | BRACKET | 1 | SN: 17712-@ |
|||
| ? | 6162-63-1811 | GASKET | 1 | SN: 17712-@ |
|||
| ? | 01010-81035 | BOLT | 1 | SN: 17712-@ |
|||
| ? | 01010-81025 | BOLT | 1 | SN: 17712-@ |
|||
| ? | 01602-01030 | WASHER,SPRING | 1 | SN: 17712-@ |
|||
| ? | 01640-21016 | WASHER | 1 | SN: 17712-@ |
|||
| ? | 6162-63-1630 | SHAFT | 1 | SN: 17712-@ |
|||
| ? | 6162-63-6560 | ELBOW | 1 | SN: 17712-@ |
|||
| ? | 6162-63-6570 | CONNECTOR | 1 | SN: 17712-@ |
|||
| ? | 6162-63-2161 | GASKET | 1 | SN: 17712-@ |
|||
| ? | 07000-02075 | O-RING | 1 | SN: 17712-@ |
|||
| ? | 07000-G2070 | O-RING | 1 | SN: 17712-@ |
|||
| ? | 01010-81235 | BOLT | 2 | SN: 17712-@ |
|||
| ? | 01010-81035 | BOLT | 2 | SN: 17712-@ |
|||
| ? | 01011-81015 | BOLT | 2 | SN: 17712-@ |
|||
| ? | 01602-01236 | WASHER,SPRING | 2 | SN: 17712-@ |
|||
| ? | 01602-01030 | WASHER,SPRING | 4 | SN: 17712-@ |
|||
| ? | 6162-63-6510 | ELBOW | 1 | SN: 17712-@ |
|||
| ? | 195-03-14381 | GASKET | 1 | SN: 17712-@ |
|||
| ? | 6162-64-6680 | TUBE | 1 | SN: 19869-@ |
|||
| ? | 6162-63-6880 | O-RING | 2 | SN: 17712-@ |
|||
| ? | 01010-81030 | BOLT | 2 | SN: 17712-@ |
|||
| ? | 01010-80820 | BOLT | 2 | SN: 19869-@ |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 17712-@ |
|||
| ? | 01678-00826 | WASHER,SPRING | 2 | SN: 19869-@ |
|||
| ? | 6162-63-6850 | SPRING | 2 | SN: 19869-@ |
|||
| ? | 6162-83-6270 | STAY | 1 | SN: 19869-@ |
|||
| ? | 6162-13-5830 | CLAMP | 1 | SN: 19869-@ |
|||
| ? | 01010-81025 | BOLT | 1 | SN: 19869-@ |
|||
| ? | 01643-31032 | WASHER | 3 | SN: 19869-@ |
|||
| ? | 01580-01008 | NUT | 1 | SN: 19869-@ |
|||
| ? | 01010-81040 | BOLT | 1 | SN: 19869-@ |
