| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 257-80-47100 | PUMP ASS'Y,HST | 1 | SN: 2001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6101 AND 6102. | ||||||
| ? | 257-81-41110 | • HOUSING | 1 | SN: 2001- |
|||
| ? | 257-81-41120 | • SEAL | 1 | SN: 2001- |
|||
| ? | 257-81-41130 | • PLATE | 1 | SN: 2001- |
|||
| ? | 257-81-41140 | • BLOCK | 1 | SN: 2001- |
|||
| ? | 257-81-41150 | • GASKET | 1 | SN: 2001- |
|||
| ? | 257-81-41160 | • BEARING,NEEDLE | 1 | SN: 2001- |
|||
| ? | 257-81-41170 | • PIN | 1 | SN: 2001- |
|||
| ? | 257-81-41180 | • PIN | 2 | SN: 2001- |
|||
| ? | 257-81-41190 | • SCREW | 2 | SN: 2001- |
|||
| ? | 257-81-41210 | • SCREW | 2 | SN: 2001- |
|||
| ? | 258-81-21220 | • PLUG | 2 | SN: 2001- |
|||
| ? | 257-81-41230 | • PLUG | 3 | SN: 2001- |
|||
| ? | 257-81-41240 | • PLUG | 1 | SN: 2001- |
|||
| ? | 257-81-41250 | • PLATE | 1 | SN: 2001- |
|||
| ? | 257-81-41260 | • SCREW | 2 | SN: 2001- |
|||
| ? | 257-81-41270 | • BRACKET | 1 | SN: 2001- |
|||
| ? | 257-81-41280 | • SHAFT | 1 | SN: 2001- |
|||
| ? | 257-81-41290 | • BEARING,BALL | 1 | SN: 2001- |
|||
| ? | 257-81-41310 | • RING | 1 | SN: 2001- |
|||
| ? | 257-81-41320 | • O-RING | 1 | SN: 2001- |
|||
| ? | 257-81-41330 | • CARRIER | 1 | SN: 2001- |
|||
| ? | 257-81-41340 | • RING | 1 | SN: 2001- |
|||
| ? | 257-81-41350 | • PLATE | 1 | SN: 2001- |
|||
| ? | 257-81-41360 | • PIN | 1 | SN: 2001- |
|||
| ? | 257-81-41370 | • GEROTOR | 1 | SN: 2001- |
|||
| ? | 257-81-41380 | • SPACER | 1 | SN: 2001- |
|||
| ? | 257-81-41390 | • BALL | 1 | SN: 2001- |
|||
| ? | 257-81-41410 | • O-RING | 1 | SN: 2001- |
|||
| ? | 257-81-41420 | • O-RING | 1 | SN: 2001- |
|||
| ? | 257-81-41430 | • O-RING | 1 | SN: 2001- |
|||
| ? | 257-81-41440 | • PLUG | 1 | SN: 2001- |
|||
| ? | 258-81-21130 | • O-RING | 1 | SN: 2001- |
|||
| ? | 257-81-41460 | • SHIM | A/R | SN: 2001- |
|||
| ? | 257-81-41470 | • SPRING | 1 | SN: 2001- |
|||
| ? | 257-81-41480 | • POPPET | 1 | SN: 2001- |
|||
| ? | 257-81-41490 | • CAP | 1 | SN: 2001- |
|||
| ? | 257-81-41510 | • PLUG | 1 | SN: 2001- |
|||
| ? | 257-81-41520 | • CONNECTOR | 1 | SN: 2001- |
|||
| ? | 257-81-41530 | • CONNECTOR | 1 | SN: 2001- |
|||
| ? | 258-81-21590 | • PLUG | 1 | SN: 2001- |
|||
| ? | 257-81-41550 | • PLUG | 2 | SN: 2001- |
|||
| ? | 257-81-41560 | • O-RING | 2 | SN: 2001- |
|||
| ? | 257-81-41570 | • O-RING | 2 | SN: 2001- |
|||
| ? | 258-81-21750 | • SPRING | 2 | SN: 2001- |
|||
| ? | 257-81-41590 | • RING | 2 | SN: 2001- |
|||
| ? | 257-81-41610 | • VALVE | 2 | SN: 2001- |
|||
| ? | 257-81-41620 | • PLATE | 1 | SN: 2001- |
|||
| ? | 257-81-41630 | • BEARING | 2 | SN: 2001- |
|||
| ? | 257-81-41640 | • SHIM | A/R | SN: 2001- |
|||
| ? | 257-81-41650 | • SPACER | 1 | SN: 2001- |
|||
| ? | 257-81-41660 | • O-RING | 2 | SN: 2001- |
|||
| ? | 257-81-41670 | • COVER | 1 | SN: 2001- |
|||
| ? | 257-81-41690 | • SCREW | 4 | SN: 2001- |
|||
| ? | 257-81-41710 | • KEY | 1 | SN: 2001- |
|||
| ? | 257-81-41720 | • COVER | 1 | SN: 2001- |
|||
| ? | 257-81-41730 | • SCREW | 4 | SN: 2001- |
|||
| ? | 257-81-41740 | • WASHER | 4 | SN: 2001- |
|||
| ? | 257-81-41750 | • ELBOW | 2 | SN: 2001- |
|||
| ? | 257-81-41760 | • HOSE | 1 | SN: 2001- |
|||
| ? | (257-81-41800) | • MDC ASS'Y | 1 | SN: 2001- |
