| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (257-20-56800) | HARNESS | 1 | SN: 2201- |
|||
| ? | (257-20-46802) | HARNESS | 1 | SN: 2086-2200 |
|||
| ? | (257-20-46801) | HARNESS | 1 | SN: 2036-2085 |
|||
| ? | (257-20-46800) | HARNESS | 1 | SN: 2001-2035 |
|||
| ? | 258-30-16710 | SWITCH,NEUTRAL | 2 | SN: 2001- |
|||
| ? | 258-20-16910 | SWITCH,TURN SIGNAL | 1 | SN: 2001- |
|||
| ? | 258-20-36940 | SEAT | 1 | SN: 2001- |
|||
| ? | 266-52-76900 | FUSE | 1 | SN: 2001-2200 |
|||
| ? | 258-20-56290 | BOX,FUSE | 1 | SN: 2201- |
|||
| ? | 258-20-16200 | BOX,FUSE | 1 | SN: 2001-2200 |
|||
| ? | 258-20-56210 | • FUSE ? 5A | 1 | SN: 2201- |
|||
| ? | 258-20-56220 | • FUSE ? 10A | 1 | SN: 2201- |
|||
| ? | 258-20-56230 | • FUSE ? 15A | 1 | SN: 2201- |
|||
| ? | 258-20-56240 | • FUSE ? 20A | 1 | SN: 2201- |
|||
| ? | 258-20-56250 | • FUSE ? 30A | 1 | SN: 2201- |
|||
| ? | 01010-80625 | BOLT | 2 | SN: 2201- |
|||
| ? | 01220-40516 | SCREW | 2 | SN: 2001-2200 |
|||
| ? | 01602-20619 | WASHER,SPRING | 2 | SN: 2201- |
|||
| ? | 01602-20513 | WASHER,SPRING | 2 | SN: 2001-2200 |
|||
| ? | 01580-10605 | NUT | 2 | SN: 2201- |
|||
| ? | 01580-10504 | NUT | 2 | SN: 2001-2200 |
|||
| ? | 2691-2-16200 | LAMP ASS'Y | 1 | SN: 2001- |
|||
| ? | 2691-2-16260 | • BULB ? 25W | 1 | SN: 2001- |
|||
| ? | 01010-80820 | BOLT | 2 | SN: 2001- |
|||
| ? | 01601-20825 | WASHER,SPRING | 2 | SN: 2001- |
|||
| ? | 258-20-26970 | BUZZER | 1 | SN: 2001- |
|||
| ? | 01602-20825 | WASHER,SPRING | 1 | SN: 2001- |
|||
| ? | 01580-10806 | NUT | 1 | SN: 2001- |
|||
| ? | 257-20-16630 | BATTERY | 1 | SN: 2001- |
|||
| ? | 257-20-46910 | CABLE | 1 | SN: 2001- |
|||
| ? | 265-20-13740 | CAP | 1 | SN: 2001- |
|||
| ? | 266-20-22240 | CABLE | 1 | SN: 2001- |
|||
| ? | 01010-80820 | BOLT | 2 | SN: 2001- |
|||
| ? | 01602-20825 | WASHER,SPRING | 2 | SN: 2001- |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 2201- |
|||
| ? | 01643-30823 | WASHER | 1 | SN: 2001-2200 |
|||
| ? | 258-20-16110 | HOLDER | 1 | SN: 2001- |
|||
| ? | 257-20-16620 | CUSHION | 3 | SN: 2001- |
|||
| ? | 258-20-16871 | CABLE | 1 | SN: 2001-2200 |
|||
| ? | 258-20-56940 | FUSE | 1 | SN: 2201- |
|||
| ? | 203-06-57241 | FUSIBLE LINK | 1 | SN: 2036-2200 |
|||
| ? | 258-20-56950 | BRACKET | 1 | SN: 2201- |
|||
| ? | 258-20-36950 | BRACKET | 1 | SN: 2036-2200 |
|||
| ? | 01580-10605 | NUT | 1 | SN: 2201- |
|||
| ? | 01602-20619 | WASHER,SPRING | 1 | SN: 2201- |
|||
| ? | 01580-11008 | NUT | 1 | SN: 2201- |
|||
| ? | 01602-21030 | WASHER,SPRING | 1 | SN: 2201- |
|||
| ? | 01643-30623 | WASHER | 2 | SN: 2201- |
