| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (56B-13-10006) | TORQFLOW ASS'Y | 1 | SN: 1001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS. | ||||||
| ? | 56B-15-15870 | • COVER | 1 | SN: 1001- |
|||
| ? | 56B-15-15880 | • COVER | 1 | SN: 1001- |
|||
| ? | 01010-81020 | • BOLT | 4 | SN: 1001- |
|||
| ? | 01643-31032 | • WASHER | 4 | SN: 1001- |
|||
| ? | 7861-93-3320 | • SENSOR | 2 | SN: 1001- |
|||
| ? | 7861-93-2330 | • SENSOR | 3 | SN: 1001- |
|||
| ? | 08034-00414 | • BAND | 7 | SN: 1001- |
|||
| ? | 7861-93-1670 | • SENSOR,PRESSURE | 1 | SN: 1001- |
|||
| ? | 04434-53411 | • CLIP | 1 | SN: 1001- |
|||
| ? | 144-874-6960 | • CLIP | 1 | SN: 1001- |
|||
| ? | 08036-21014 | • CLIP | 4 | SN: 1001- |
|||
| ? | 08193-21012 | • CLIP | 6 | SN: 1001- |
|||
| ? | 01010-81020 | • BOLT | 6 | SN: 1001- |
|||
| ? | 01643-31032 | • WASHER | 6 | SN: 1001- |
|||
| ? | 56B-15-15811 | • WIRING HARNESS | 1 | SN: 1001- |
|||
| ? | 09608-05080 | • PLATE¤ NAME | 1 | SN: 1001- |
|||
| ? | 04418-13060 | • SCREW | 4 | SN: 1001- |
|||
| ? | 04530-12438 | • BOLT | 4 | SN: 1001- |
|||
| ? | 56B-61-12241 | • BLOCK | 1 | SN: 1001- |
|||
| ? | 01011-81050 | • BOLT | 4 | SN: 1001- |
|||
| ? | 01643-31032 | • WASHER | 4 | SN: 1001- |
|||
| ? | 07000-73038 | • O-RING (K1) | 1 | SN: 1001- |
