| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (56B-13-10006) | TORQFLOW ASS'Y | 1 | SN: 1001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS. | ||||||
| ? | 56B-15-18114 | • TUBE | 1 | SN: 1001- |
|||
| ? | 56B-15-18123 | • TUBE | 1 | SN: 1001- |
|||
| ? | 56B-15-18132 | • TUBE | 1 | SN: 1001- |
|||
| ? | 56B-15-18143 | • TUBE | 1 | SN: 1001- |
|||
| ? | 56B-15-18172 | • TUBE | 1 | SN: 1001- |
|||
| ? | 20U-62-42210 | • NIPPLE | 8 | SN: 1001- |
|||
| ? | 02782-10516 | • ELBOW | 2 | SN: 1001- |
|||
| ? | 02896-61015 | • O-RING (K3) | 10 | SN: 1001- |
|||
| ? | 07002-12034 | • O-RING (K3) | 10 | SN: 1001- |
|||
| ? | 56B-15-18711 | • BRACKET | 1 | SN: 1001- |
|||
| ? | 56B-15-18720 | • BRACKET | 1 | SN: 1001- |
|||
| ? | 04434-51510 | • CLIP | 3 | SN: 1001- |
|||
| ? | 01010-81020 | • BOLT | 1 | SN: 1001- |
|||
| ? | 01643-31032 | • WASHER | 1 | SN: 1001- |
|||
| ? | 01435-01016 | • BOLT | 3 | SN: 1001- |
|||
| ? | 01010-81045 | • BOLT | 2 | SN: 1001- |
|||
| ? | 01643-31032 | • WASHER | 2 | SN: 1001- |
|||
| ? | 56B-15-18150 | • TUBE | 1 | SN: 1001- |
|||
| ? | 56B-15-18161 | • TUBE | 1 | SN: 1001- |
|||
| ? | 07206-31824 | • BOLT | 4 | SN: 1001- |
|||
| ? | 07005-02416 | • GASKET (K3) | 8 | SN: 1001- |
|||
| ? | 56B-15-18181 | • TUBE | 1 | SN: 1001- |
|||
| ? | 07206-31520 | • BOLT | 2 | SN: 1001- |
|||
| ? | 07005-02012 | • GASKET (K3) | 4 | SN: 1001- |
|||
| ? | 42A-16-11210 | • PLATE | 1 | SN: 1001- |
|||
| ? | 04434-51810 | • CLIP | 1 | SN: 1001- |
